Marantz DV4200 - Technical Specifications

1
1. TECHNICAL SPECIFICATIONS
DVD Player
Power supply (S) ............................................................................................................................... AC 220~230V, 50/60 Hz
Power supply (U) .............................................................................................................................................AC 120V, 60 Hz
Power supply (N) .............................................................................................................................................AC 230V, 50 Hz
Power supply (F).........................................................................................................................................AC 100V, 50/60 Hz
Power supply (A) .................................................................................................................................... AC 110~240V, 50 Hz
Power consumption ..........................................................................................................................................................16 W
Weight ............................................................................................................................................................. 7.1 lbs. (3.2 kg)
External dimensions (W X H X D) ......................................................................... 17.3" X 3.5" X 10.0" (440 x 88 x 254 mm)
Signal system (U, F) ....................................................................................................................................................... NTSC
Signal system (N, S)...............................................................................................................................................PAL, NTSC
Laser Semiconductor laser, wavelength ..................................................................................... 650 nm (DVD), 780 nm (CD)
Frequency range (audio) .......................................................................................................DVD: fs = 96 kHz 4 Hz - 44 kHz
................................................................................................................ fs = 48 kHz 4 Hz - 22 kHz
............................................................................................................................ CD: 4 Hz - 20 kHz
Signal-to-noise ratio (audio) ............................................................................................................. More than 105 dB (EIAJ)
Dynamic range (audio) ..................................................................................................................... More than 100 dB (EIAJ)
Harmonic distortion (audio) .........................................................................................................................................0.003 %
Wow and flutter Below measurable level ....................................................................(less than + 0.001 % (W.PEAK)) (EIAJ)
Operating conditions .................................................Temperature: 41°F to 95°F (5°C to 35°C), Operation status: Horizontal
Outputs
Video output ...................................................................................................1.0 V (p-p), 75 , negativ e sync., RCA jack x 1
S-video output (Y) ..................................................................................1.0 V (p-p), 75 , negativ e sync., Mini DIN 4-pin x 1
(C) .................................................................................................................................... 0.286 V (p-p), 75
Component video output (Y) (U, F, S, A) ......................................................1.0 V (p-p), 75 , negativ e sync., RCA jack x 1
(CB)/(CR) (U, F, S, A) .......................................................................................... 0.7 V (p-p), 75
R/G/B output (N)................................................................................................................ 0.7 Vp-p 21-pin SCART connector
Audio output (digital audio)..................................................................................................... 0.5 V (p-p), 75 , RCA jac k x 1
Audio output (optical audio) (F, A, S, N) ................................................................................................. Optical connector x 1
Audio output (analog audio) .................................................................... 2.0 Vrms (1 kHz, 0 dB), 330 , RCA jac k (L, R) x 2
Supplied Accessories
Video cable .......................................................................................................................................................................1
Audio cable .......................................................................................................................................................................1
System Control cable........................................................................................................................................................ 1
Remote control ................................................................................................................................................................. 1
Batteries............................................................................................................................................................................ 2
Designs and specifications are subject to change without notice.
REMARK
This service manual corresponds to service modification code number "MZ01" and later. When exchanging MAIN
PCB on the product of the service modification code "MZ00", it is necessary to also exchange the following parts on
the I/O PCB simultaneously.
(The service modification code is mentioned in the number label on the rear panel. Ex.MZ01xxxxxxxxxx)
Two kinds of MPEG ICs (IC501) exist in this model. Since the conventional IC (Pantera-2) became a production stop,
this was generated. Since power supply voltage is changed, new IC (Pantera-2 LE) has change in a power supply
part. In the case of repair, please fix after checking the version of IC.
Service modification code
MZ00 MZ01
Location <Pantera-2> <Pantera-2 LE>
D115 1N17 Tin Wire
