Marantz DV4200 - Mechanism Section

2-1
• Top View..................................................2-2
• Top View(without Tray Disc) .................2-2
• Bottom View ...........................................2-2
1. Holder Clamp....................................2-3
1-1. Clamp Assembly Disc.......................2-3
1-1-1. Plate Clamp ..................................2-3
1-1-2. Magnet Clamp ..............................2-3
1-1-3. Clamp Upper.................................2-3
2. Tray Disc ...........................................2-3
3. Base Assembly Sled........................2-4
3-1. Gear Assembly Feed........................2-4
3-2. Gear Assembly Middle......................2-4
3-3. Gear Assembly Rack........................2-4
4. Rubber Rear......................................2-4
5. Frame Assembly Up/Down..............2-5
6. Belt Loading......................................2-5
7. Gear Pulley .......................................2-5
8. Gear Loading....................................2-5
9. Guide Up/Down.................................2-5
10. PWB Assembly Loading................2-5
11. Base Main........................................2-5
1. Tools and Fixtures for SVC.............2-6
2. Install Process..................................2-6
3. Adjustment Process.........................2-7
CONTENTS
14. MECHANISM SECTION
DECK MECHANISM PARTS
LOCATIONS
DECK MECHANISM ADJUSTMENT
DECK MECHANISM
DISASSEMBLY
1. Reading upgrade disc......................2-8
2. Reset and MICOM version check....2-8
3. Error messege...................................2-8
1. Deck Mechanism Exploded View
and Parts list.....................................2-9
EXPLODED VIEW
HOW TO UPGRADE BY
UPGRADE DISC
