Marantz DV4200 - Page 51

65
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
F602
F608
nsp FILTER CFI06B1H101MF
2.5K/T
nsp
F612
F, A, S, U nsp FILTER CFI06B1H101MF
2.5K/T
nsp
F613
F, A, S, U nsp FILTER CFI06B1H101MF
2.5K/T
nsp
F615 nsp FILTER CFI06B1H101MF
2.5K/T
nsp
F616 nsp FILTER CFI06B1H101MF
2.5K/T
nsp
F617 N nsp FILTER CFI06B1H101MF
2.5K/T
nsp
F618 N nsp FILTER CFI06B1H101MF
2.5K/T
nsp
F622 N nsp FILTER CFI06B1H101MF
2.5K/T
nsp
FH101 nsp HOLDER FUSE CLIP nsp
FH102 nsp HOLDER FUSE CLIP nsp
JK601
F, N, A, S 9322 155 28667 JACK FIBER OPTIC
GP1FA550TZ
*YJ002520R
JK602
F, A, S, U nsp JACK RCA DIN *YT002680R
JK602 N 9965 000 11332 JACK RCA/DIN-17G *YT002690R
JK603 N 9965 000 11333 JACK SCART 2F-21P 3.81
BAEUN
*YT002700R
L101 F, U nsp FILTER LS-AI99F-009 *FN000130R
L101 N, A, S 9965 000 11334 FILTER V-04350 LS BULK *FN000140R
L102 nsp COIL CHOKE 22mH nsp
L103 nsp COIL CHOKE 20 H nsp
L201
nsp FILTER HB-1M2012-102JT 3K nsp
L204
L207 nsp FILTER HB-1M2012-102JT 3K nsp
L208 nsp FILTER HB-1M2012-102JT 3K nsp
L211 nsp FILTER HB-1M2012-102JT 3K nsp
L2A1 nsp FILTER HB-1M2012-102JT 3K nsp
L2A2 nsp FILTER HB-1M2012-102JT 3K nsp
L301 nsp FILTER HB-1M2012-102JT 3K nsp
L302 nsp FILTER HB-1M2012-102JT 3K nsp
L3F1 nsp FILTER HB-1M2012-102JT 3K nsp
L3F2 nsp FILTER HB-1M2012-102JT 3K nsp
L401 nsp INDUCTOR 100M K 6X6 L5 nsp
L501
nsp FILTER HB-1M2012-102JT 3K nsp
L506
L601 N nsp INDUCTOR 100M K 6X6 L5 nsp
L602 N nsp INDUCTOR 100M K 6X6 L5 nsp
L603 nsp INDUCTOR 1.0M K 2.3X3.4 L5 nsp
L604 nsp INDUCTOR 1.0M K 2.3X3.4 L5 nsp
L901 nsp INDUCTOR 100M K 6X6 L5 nsp
L902 nsp INDUCTOR 100M K 6X6 L5 nsp
P3301 nsp CONN. 04-6232-115-008-800 nsp
P4301 nsp CONN. 2254-30P-T nsp
P5402 nsp CONN. 2254-30S-T nsp
P5901 nsp CONN. 2254-30S-T nsp
P9501 nsp CONN. 2254-30P-T nsp
P9901 nsp CONN. GIL-S/9073AN 4 nsp
P9902 nsp CONN. GIL-S-04P-S2T2-EF 4P nsp
P9903 nsp CONN. GIL-S/9073AN 3P nsp
P9904 nsp CONN. GIL-S-03P-S2T2-EF nsp
PBJIG nsp PWB ASSY TOTAL DVD-3000’S
JIG ASSY
*DV3100JIG
PBP00 nsp PWB ASSY DVM4000S LED nsp
PBT00 nsp PWB ASSY DVM4000S KEY nsp
PMD02 nsp CONN.
00-6232-023-006-800 23P
nsp
PMD03 nsp CONN.
00-6232-020-006-800 20 P
nsp
PW101 nsp CONN. GP390 LGC 3P nsp
RC901 9965 000 07015 IR RECEIVER
TSOP2836WE1 36.7KHz
*HW100550R
SW601 N, A, S 9965 000 11337 SWITCH SLIDE
SKQ-23D15-G5-NA
*SS000620R
SW602 9965 000 11338 SWITCH TACT CSS-4206 *SS000730R
SW603 9965 000 11339 SWITCH SLIDE
SKQ-22H06-G5-NA
*SS000740R
SW901
9965 000 07017 SWITCH TACT THVV502GAA *SP001000R
SW906
SW908 9965 000 07017 SWITCH TACT THVV502GAA *SP001000R
T101 F, U nsp MAINS TRANSF.
KSE-021K/LSE-021K
*TS001600R
T101 N, A, S 9965 000 07018 MAINS TRANSF.
SHT-023T/KSE-023T
*TS001170R
V101 nsp VARISTOR SVC681D-10A
4.O CUT
nsp
X201 9965 000 11340 CRYSTAL HC-49/S
AXIAL 33.8688MHz
*JX000870R
X501 9965 000 11341 CRYSTAL HC-49/S
AXIAL 27MHz 20P
*JX000880R
X901
9965 000 11342
RESONATOR
CSTLS5M00G53-A0
*FQ000540R
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
