Marantz DV9600 - Page 124

[PM01] Q102(Back End microprocessor) : M32102S6FP
Pin PORT SIGNAL NAME I/O DESCRIPTION
73 D15 HD15 I/O Data I/O
74 D14 HD14 I/O Data I/O
75 D13 GD13 I/O Data I/O
76 VCCX +3.3V
77 D12 HD12 I/O Data I/O
78 D11 HD11 I/O Data I/O
79 D10 HD10 I/O Data I/O
80 VSS GND
81 D9 HD9 I/O Data I/O
82 D8 HD8 I/O Data I/O
83 D7 HD7 I/O Data I/O
84 D6 HD6 I/O Data I/O
85 D5 HD5 I/O Data I/O
86 D4 HD4 I/O Data I/O
87 D3 HD3 I/O Data I/O
88 D2 HD2 I/O Data I/O
89 D1 HD1 I/O Data I/O
90 D0 HD0 I/O Data I/O
91 ROMSZ GND I PULL DOWN
92 VSS GND
93 HLDA# N.C. O
94 HOLD# --- I PULL UP
95 VCCX +3.3V
96 BSEL0# FROMCS O Chip enable to FlashROM
97 P03/BSEL1# MC_BSEL1 O Chip selection to M65776.
98 P04/BSEL2# N.C. O
99 P05/BSEL3# N.C. O
100 P06/BSEL4# N.C. O
101 P07/BSEL5# N.C. O
102 READY# MC_RDY I Ready signal from M65776.
103 P17/RD/WR# N.C. O
104 RS# MC_RS O output enable to Flash ROM.
105 WS0#/DQM0 MC_WS0 O Byte High Enable signal output
106 WS1#/DQM1 MC_WS1 O Enable output of extended port
107 WS2#/DQM2/A30 A30 O Address output
108 P27/WS3#/DQM3 DRVRST O Reset signal output to CXD1885. Reset=L
109 P67/DWE# OPN_DRV O Tray Open/Close control output
110 P66/DCAS# CLS_DRV O Tray Open/Close control output
111 P65/DRAS# OPN_SW I Tray open detection signal. Detection=L
112 P64/DCAS1# CLS_SW I Tray close detection signal. Detection=L
113 VCCX +3.3V
114 P63/DCS0# RESET O Reset signal output to M65776. Reset=L
115 P62/DCKE AMUTE O Audio mute control output. MUTE ON=L
116 A29/MA0 A29 O Address output
117 A28/MA1 A28 O Address output
118 A27/MA2 A27 O Address output
119 A26/MA3 A26 O Address output
120 A25/MA4 A25 O Address output
121 VSS GND
122 A24/MA5 A24 O Address output
123 A23/MA6 A23 O Address output
124 A22/MA7 A22 O Address output
125 A21/MA8 A21 O Address output
126 A20/MA9 A20 O Address output
127 VCC +2.5V
128 VSS GND
129 A19/MA10 A19 O Address output
130 A18/MA11 A18 O Address output
131 A17/MA12 A17 O Address output
132 A16/MA13 A16 O Address output
133 A15 A15 O Address output
134 VCCX +3.3V
135 A14 A14 O Address output
136 A13 A13 O Address output
137 A12 A12 O Address output
138 A11 A11 O Address output
139 A10 A10 O Address output
140 A9 A9 O Address output
141 A8 N.C. O
142 VSS GND
143 P70 DSD/PCM O Select DSD/PCM. PCM=L
144 VCCX +3.3V
