[PM01] QK01 : CM0039AF
No. Pin name I/O
3
Attribute Description
1 DI0 IN CMOS
Image data input pin (LSB).
Connect it to the ground for 8-bit data input.
2 DI1 IN CMOS
Image data input pin.
Connect it to the ground for 8-bit data input.
3 DI2 IN CMOS Image data input pin.
4 DI3 IN CMOS Image data input pin.
5 DI4 IN CMOS Image data input pin.
6 DI5 IN CMOS Image data input pin.
7 DI6 IN CMOS Image data input pin.
8 DI7 IN CMOS Image data input pin.
9 DI8 IN CMOS Image data input pin.
10 DI9 IN CMOS
Image data input pin (MSB).
Start from the MSB when inputting 8-bit data.
11 VDDE P - VDD for IO (+ 3.3 V).
12 VDDI P - VDD for Core (+ 1.8 V).
13 CLKI IN CMOS 27 MHz system clock input pin.
14 VSS P - Digital ground.
15 PLL_VDD P -
VDD exclusively for PLL (+ 1.8 V).
Separation from VDD for Core (+ 1.8 V) is
recommended.
16 S IN CMOS
PLL enable input pin. Set it to High after power supply
voltage and CLKI are stably supplied.
17 PLL_GND P -
Ground exclusively for PLL.
Separation from the digital ground is recommended.
18 VSS P - Digital ground.
19 VSS P - Digital ground.
20 TEST0 IN CMOS
Input pin exclusively for testing.
Connect it to the ground.
21 TEST1 IN CMOS
Input pin exclusively for testing.
Connect it to the ground.
22 VSS P - Digital ground.
23 VDD18 P -
Digital VDD (+ 1.8 V) exclusively for DAC.
Share the power source with VDD (+ 1.8 V) for Core.
24 VDD33 P -
Analog VDD (+ 3.3 V) exclusively for DAC.
Separate it from VDD (+ 3.3 V) for IO.
25 DAGND7 P -
Analog ground exclusively for DAC.
Separate it from the digital ground.
26 DAGND6 P -
Analog ground exclusively for DAC.
Separate it from the digital ground.
27 DAOUT6 OUT Analog
Analog video image output pin (Pr/R).
Connect it to the emitter-follower circuit.
28 DAVDD6 P -
Analog VDD (+ 3.3 V) exclusively for DAC.
Separate it from VDD (+ 3.3 V) for IO.
29 DAGND5 P -
Analog ground exclusively for DAC.
Separate it from the digital ground.
30 DAOUT5 OUT Analog
Analog video image output pin (Pb/B).
Connect it to the emitter-follower circuit.
31 DAVDD5 P -
Analog VDD (+ 3.3 V) exclusively for DAC.
Separate it from VDD (+ 3.3 V) for IO.
32 DAGND4 P -
Analog ground exclusively for DAC.
Separate it from the digital ground.
174
