Marantz DV9600 - Page 162

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PWB
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
P801 C852
/
K1G ns
p
00MOB10803570 ELECT. CAP. 1000U 35V
(
ALP
)(
LF
)
-BLOCK CAP
P801 C852
/
L1G ns
p
00MOB10803570 ELECT. CAP. 1000U 35V
(
ALP
)(
LF
)
-BLOCK CAP
P801 C852
/
N1S ns
p
00MOA22802540 ELECT. CAP. 2200UF M 25V CILMIC
(
ARS
)
P801 C852
/
S1G ns
p
00MOB10803570 ELECT. CAP. 1000U 35V
(
ALP
)(
LF
)
-BLOCK CAP
P801 C852
/
U1B ns
p
00MOB10803510 ELECT. CAP. 35V 1000UF BLOC
K
P801 C853 ns
p
00MOA47602520 ELECT. CAP. 47 UF M 25V RA-2
P801 C854 ns
p
00MOA47602520 ELECT. CAP. 47 UF M 25V RA-2
P801 C855 F B ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M-H5#PE-T2
(
220UF 25V
)
P801 C855 F N ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M-H5#PE-T2
(
220UF 25V
)
P801 C855
/
K1G ns
p
00MOA227016Z0 ELECT. CAP. ROS-16V 221M-H5#PE-T2
(
220UF 16V
)
P801 C855
/
L1G ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M-H5#PE-T2
(
220UF 25V
)
P801 C855
/
N1S ns
p
00MOA227016Z0 ELECT. CAP. ROS-16V 221M-H5#PE-T2
(
220UF 16V
)
P801 C855
/
S1G ns
p
00MOA227016Z0 ELECT. CAP. ROS-16V 221M-H5#PE-T2
(
220UF 16V
)
P801 C855
/
U1B ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M-H5#PE-T2
(
220UF 25V
)
P801 C856 F B ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M-H5#PE-T2
(
220UF 25V
)
P801 C856 F N ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M-H5#PE-T2
(
220UF 25V
)
P801 C856
/
K1G ns
p
00MOA227016Z0 ELECT. CAP. ROS-16V 221M-H5#PE-T2
(
220UF 16V
)
P801 C856
/
L1G ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M-H5#PE-T2
(
220UF 25V
)
P801 C856
/
N1S ns
p
00MOA227016Z0 ELECT. CAP. ROS-16V 221M-H5#PE-T2
(
220UF 16V
)
P801 C856
/
S1G ns
p
00MOA227016Z0 ELECT. CAP. ROS-16V 221M-H5#PE-T2
(
220UF 16V
)
P801 C856
/
U1B ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M-H5#PE-T2
(
220UF 25V
)
P801 C861 ns
p
00MOA22801620 ELECT. CAP. 2200UF 16
V
P801 C862 ns
p
00MOA22701020 ELECT. CAP. 220 UF M 10V RA-2
P801 C863 ns
p
00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
P801 C871 ns
p
00MOA10802520 ELECT. CAP. 1000 UF M 25V RA-2
P801 C872 ns
p
00MOA10405020 ELECT. CAP. 0.1 UF M 50V RA-2
P801 C873 ns
p
00MOA10606320 ELECT. CAP. 10 UF 63V RA-2
P801 D801 00MHD20031290 00MHD20031290 DIODE ! S1WB
(
A
)
60 30A 600
V
P801 D802 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P801 D803 00MHD32201000 00MHD32201000 ZENER DIODE 22V ZENER EQUIVALENT
P801 D804 00MHD20049080 00MHD20049080 DIODE ! AG01 400V 0.7
A
P801 D805 00MHD31801000 00MHD31801000 ZENER DIODE 18V ZENER EQUIVALENT
P801 D806 00MHD30911000 00MHD30911000 ZENER DIODE 9.1V ZENER EQUIVALENT
P801 D807 00MHD20049080 00MHD20049080 DIODE ! AG01 400V 0.7
A
P801 D808 00MHD32001000 00MHD32001000 ZENER DIODE 20V ZENER EQUIVALENT
P801 D810 00MHD30911000 00MHD30911000 ZENER DIODE 9.1V ZENER EQUIVALENT
P801 D811 00MHD20050080 00MHD20050080 DIODE ! RK46
(
SBD
)
60V 3.5
A
P801 D812 00MHD20050080 00MHD20050080 DIODE ! RK46
(
SBD
)
60V 3.5
A
P801 D814 00MHD20050080 00MHD20050080 DIODE ! RK46
(
SBD
)
60V 3.5
A
P801 D815 00MHD20050080 00MHD20050080 DIODE ! RK46
(
SBD
)
60V 3.5
A
P801 D817 00MHD20053080 00MHD20053080 DIODE ! EK19 90V 1.5
A
P801 D818 00MHD32001000 00MHD32001000 ZENER DIODE 20V ZENER EQUIVALENT
P801 D819 00MHD30911000 00MHD30911000 ZENER DIODE 9.1V ZENER EQUIVALENT
P801 D841 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P801 D845 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100
V
P801 D851 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100
V
P801 D852 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100
V
P801 D853 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100
V
P801 D854 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100
V
P801 D855 00MHD31001000 00MHD31001000 ZENER DIODE 10V ZENER EQUIVALENT
P801 D856 00MHD31001000 00MHD31001000 ZENER DIODE 10V ZENER EQUIVALENT
P801 D857 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P801 D858 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P801 D861 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100
V
P801 D862 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100
V
P801 D863 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100
V
P801 D864 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100
V
P801 D871 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100
V
P801 D872 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100
V
P801 D873 00MHD20055100 00MHD20055100 DIODE SHOTTKY 11EQS10 1A 100
V
P801 D875 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P801 F801 00MFS20250200 00MFS20250200 FUSE # T2.5A/250V TR5 NO.19372
(T
P801 F802 00MFS20025200 00MFS20025200 FUSE # T250MA/250V TR5 NO.19372
(
TP
)
P801 F803 00MFS20315200 00MFS20315200 FUSE # FUSE 3.15A 250V SEMKO VDE
P801 F851 00MFS20050200 00MFS20050200 FUSE # T500MA/250V TR5 NO.19372
(
TP
)
P801 F852 00MFS20050200 00MFS20050200 FUSE # T500MA/250V TR5 NO.19372
(
TP
)
P801 F853 00MFS20050200 00MFS20050200 FUSE # T500MA/250V TR5 NO.19372
(
TP
)
196
