NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PWB
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
P801 L801 00MLC22260130 00MLC22260130 COIL # 22MH X2 LINE FILTER
P801 L803 00MLC14734500 00MLC14734500 COIL RCH-110 47UH 2.5
A
P801 L804 00MFC90050130 00MFC90050130 FERRITE CORE BL02RN2-R62T2 FERRITE BEAD
P801 L841 00MLY1006001
0
00MLY1006001
0
RELAY # SDT-S-106LMR TV-5 DC6V 250M
W
P801 Q801 00MHF22943000 00MHF22943000 F.E.T. ! 2SK2943 900V 3
A
P801 Q802 00MHC10007130 00MHC10007130 IC FA3647P PWM CONTROL IC
P801 Q803 00MHW10032320 00MHW10032320 PHOTO UNIT ! PC-123F2 PHOTO COUPLER
P801 Q804 00MHC33036590 00MHC33036590 IC TL431CZ PROG.VOLTAGE REFERENCE
P801 Q806 00MHC10006080 00MHC10006080 IC ! SI-3050C +5V 1.5A WITH S
W
P801 Q807 00MHC10006080 00MHC10006080 IC ! SI-3050C +5V 1.5A WITH S
W
P801 Q808 00MHC3691208F 00MHC3691208F IC ! SI-3120F +12V 1A WITH S
W
P801 Q809 00MHT316272B0 00MHT316272B0 TRS. 2SC1627 O,Y 80V 300MA 600MW T
O
P801 Q812 00MHC3890809F 00MHC3890809F IC ! +8V 1A REGULATOR NJM7808F
A
P801 Q813 00MHT30001000 00MHT30001000 TRS. C2458,C1740S,C3199,ETC.
P801 Q814 00MHT316272B0 00MHT316272B0 TRS. 2SC1627 O,Y 80V 300MA 600MW T
O
P801 Q841 00MHT10001000 00MHT10001000 TRS. ! A1048,A933S,A1267,ETC.
P801 Q842 00MBA20001000 00MBA20001000 TRS. DTC114ES/UN4211 10K,10
K
P801 Q853 00MHT41415100 00MHT41415100 TRS. ! 2SD1415
A
P801 Q854 00MHT21020100 00MHT21020100 TRS. ! 2SB1020
A
P801 Q861 00MHC3690521F 00MHC3690521F IC ! BA05T 5V/1
A
P801 Q862 00MHC36J3321F 00MHC36J3321F IC ! BA033
T
P801 Q871 00MHT30001000 00MHT30001000 TRS. C2458,C1740S,C3199,ETC.
P801 Q872 00MHT30001000 00MHT30001000 TRS. C2458,C1740S,C3199,ETC.
P801 Q874 00MHT10001000 00MHT10001000 TRS. A1048,A933S,A1267,ETC.
P801 Q875 00MBA20004000 00MBA20004000 TRS. DTC114TS/UN4215 10
K
P801 R801 F B ns
p
00MRC10225820 RES. ! 2.2M OHM +- 10% 1/2W FOR U
L
P801 R801 F N ns
p
00MRC10225820 RES. ! 2.2M OHM +- 10% 1/2W FOR U
L
P801 R801
/
K1G ns
p
00MRC05105010 RES. ! 1M OHM +-5% 1W RCR60 L15
P801 R801
/
L1G ns
p
00MRC10225820 RES. ! 2.2M OHM +- 10% 1/2W FOR U
L
P801 R801
/
N1S 00MRC05105010 00MRC05105010 RES. ! 1M OHM +-5% 1W RCR60 L15
P801 R801
/
S1G ns
p
00MRC05105010 RES. ! 1M OHM +-5% 1W RCR60 L15
P801 R801
/
U1B ns
p
00MRC10225820 RES. ! 2.2M OHM +- 10% 1/2W FOR U
L
P801 R802 F B ns
p
00MGD05224160 RES. 220K OHM +-5% 1/6
W
P801 R802 F N ns
p
00MGD05224160 RES. 220K OHM +-5% 1/6
W
P801 R802
/
K1G ns
p
00MGD05334160 RES. 330K OHM +-5% 1/6
W
P801 R802
/
L1G ns
p
00MGD05224160 RES. 220K OHM +-5% 1/6
W
P801 R802
/
N1S ns
p
00MGD05334160 RES. 330K OHM +-5% 1/6
W
P801 R802
/
S1G ns
p
00MGD05334160 RES. 330K OHM +-5% 1/6
W
P801 R802
/
U1B ns
p
00MGD05224160 RES. 220K OHM +-5% 1/6
W
P801 R803 F B ns
p
00MGD05224160 RES. 220K OHM +-5% 1/6
W
P801 R803 F N ns
p
00MGD05224160 RES. 220K OHM +-5% 1/6
W
P801 R803
/
K1G ns
p
00MGD05334160 RES. 330K OHM +-5% 1/6
W
P801 R803
/
L1G ns
p
00MGD05224160 RES. 220K OHM +-5% 1/6
W
P801 R803
/
N1S ns
p
00MGD05334160 RES. 330K OHM +-5% 1/6
W
P801 R803
/
S1G ns
p
00MGD05334160 RES. 330K OHM +-5% 1/6
W
P801 R803
/
U1B ns
p
00MGD05224160 RES. 220K OHM +-5% 1/6
W
P801 R804 F B ns
p
00MGD05224160 RES. 220K OHM +-5% 1/6
W
P801 R804 F N ns
p
00MGD05224160 RES. 220K OHM +-5% 1/6
W
P801 R804
/
K1G ns
p
00MGD05334160 RES. 330K OHM +-5% 1/6
W
P801 R804
/
L1G ns
p
00MGD05224160 RES. 220K OHM +-5% 1/6
W
P801 R804
/
N1S ns
p
00MGD05334160 RES. 330K OHM +-5% 1/6
W
P801 R804
/
S1G ns
p
00MGD05334160 RES. 330K OHM +-5% 1/6
W
P801 R804
/
U1B ns
p
00MGD05224160 RES. 220K OHM +-5% 1/6
W
P801 R805 F B ns
p
00MGD05224160 RES. 220K OHM +-5% 1/6
W
P801 R805 F N ns
p
00MGD05224160 RES. 220K OHM +-5% 1/6
W
P801 R805
/
K1G ns
p
00MGD05334160 RES. 330K OHM +-5% 1/6
W
P801 R805
/
L1G ns
p
00MGD05224160 RES. 220K OHM +-5% 1/6
W
P801 R805
/
N1S ns
p
00MGD05334160 RES. 330K OHM +-5% 1/6
W
P801 R805
/
S1G ns
p
00MGD05334160 RES. 330K OHM +-5% 1/6
W
P801 R805
/
U1B ns
p
00MGD05224160 RES. 220K OHM +-5% 1/6
W
P801 R806 ns
p
00MGD05680160 RES. 68 OHM +-5% 1/6
W
P801 R807 ns
p
00MGD05103160 RES. 10K OHM +-5% 1/6
W
P801 R808 ns
p
00MGD05100160 RES. 10 OHM +-5% 1/6
W
P801 R809 00MNK05470010 00MNK05470010 METAL RES. 47 OHM +-5% 1
W
P801 R810 ns
p
00MGD05124160 RES. 120K OHM +-5% 1/6
W
P801 R811 00MNK05100010 00MNK05100010 METAL RES. 10 OHM +-5% 1
W
P801 R812 00MNL05222020 00MNL05222020 METAL RES. 0.22 OHM +- 5% 2
W
