0
Maximum allowable PHONO input level (1 kHz)
MC Low/Mid/High:
8 mV
MM :
80 mV
0
RIAA deviation (20 Hz – 20 kHz) : ±0.5 dB
0
S/N (IHF-A, 8 Ω/ohms load)
PHONO (MC Low/Mid/High) :
75 dB (0.5 mV Input)
PHONO (MM) :
88 dB (5 mV Input)
CD/TUNER/LINE/RECORDER :
107 dB (Rated output)
0
Tone Control
BASS (50 Hz) :
±10 dB
TREBLE (15 kHz) :
±10 dB
0
Operating temperature: +5 ℃ - +35 ℃
0
Power supply : AC 120 V, 60 Hz
0
Power consumption : 150 W
0
Power consumption in standby mode : 0.2 W
For the purpose of improvement, the specifications and design are subject to change without notice.
