Marantz Model 30 - Specifications

Specifications
0
RMS Power output (Simultaneous drive of both channels) : 100 W x 2 (8 Ω/ohms load, 1 kHz, T.H.D. 0.05 %)
200 W x 2 (4 Ω/ohms load, 1 kHz, T.H.D. 0.1 %)
0
Total harmonic distortion
(1 kHz, simultaneous drive of both channels, 50 W, 8 Ω/ohms
load) :
0.005 %
0
Frequency response (CD, 1 W, 8 Ω/ohms load) : 5 Hz – 50 kHz ±3 dB
0
Damping factor (8 Ω/ohms load, 20 Hz – 20 kHz) : 500
0
Input sensitivity/Input impedance
PHONO (MC Low) :
250 μV / 33 Ω/ohms
PHONO (MC Mid) :
250 μV / 100 Ω/ohms
PHONO (MC High) :
250 μV / 390 Ω/ohms
PHONO (MM) :
2.3 mV / 39 kΩ/kohms
CD/TUNER/LINE/RECORDER :
220 mV / 18 kΩ/kohms
POWER AMP :
1.0 V / 18 kΩ/kohms
0
Output voltage/Output impedance
PRE OUT :
1.6 V / 220 Ω/ohms
