G
INPUT selector knob
This selects the input source. (v p. 24)
H
Cartridge selector knob
This switches between MM/MC cartridge and selects MC cartridge
input impedance. Sets the phono equalizer of this unit according to the
type or impedance of the turntable cartridge to be connected.
MM: Set this for an MM cartridge.
MC LOW: Use this setting for an MC cartridge of less than 50 Ω/ohms.
MC MID: Use this setting for an MC cartridge of about 50 Ω/ohms.
MC HIGH: Use this setting for an MC cartridge of 100 Ω/ohms or
higher.
0
For an MC cartridge, select the input impedance closest to the impedance
recommended for the cartridge used or select a value a few times that of the
cartridge’s internal impedance.
0
If this setting change operation is performed, playback sound is output
approximately 4 seconds after the change.
I
BASS control knob
This setting adjusts the volume level for the bass. (v p. 24)
J
TREBLE control knob
This setting adjusts the volume level for the treble. (v p. 24)
K
BALANCE control knob
This adjusts the balance of the volume output from the left and right
speakers. (v p. 24)
L
VOLUME knob
These adjust the volume level. (v p. 24)
0
9, 0 and a can be adjusted when tone balance control is on. (v p. 24)
