3-7. Error Code H1-04 failure detection procedure 3-8. Error Code H1-05 failure detection procedure
Checking device. [U1103 : TMDS261B] Checking device. [U2022 : ADV7180]
Check item(29).
Replace [U1103] with a new device.
Recheck from check item (1).
Does Error Code H1-04 continue?
Check item(30).
Replace [U2022] with a new device.
Recheck from check item (1).
Does Error Code H1-05 continue?
Replace the PCB. Replace the PCB.Recheck from check item (2). Recheck from check item (2).
YES YES
NO NO
