1. Version Display Mode
q
Model destination information :
NR1609 \
\
: Region (U, N, K, F)
w
Serial Number :
SN**************
e
Firmware Package :
Package :****
r
Main µ-com :
M:*************
t
Main 1st Boot Loader :
Main FBL :**.**
y
DSP ROM :
DSP :**.**
u
Audio PLD :
Audio PLD:**.**
i
Video PLD :
Video PLD:**.**
o
GUI SFLASH :
GUI :@@$\****
@
: Model code,
$
: Brand code (Non=0, De=1, Mz=2, Mc=3),
\
: Region code (U=1, N=2, K=5, F=4, ALL=0),
*
: version
Q0
PIMG :
PIMG :********
Q1
HEOS Version :
HEOS Version
"Press "
STATUS
" button.
*.***.***
Q2
HEOS Build :
HEOS Build
"Press "
STATUS
" button.
******
Q3
HEOS Module :
HEOS Module
"Press "
STATUS
" button.
***
Q4
HEOS Cong :
HEOS Config
"Press "
STATUS
" button.
Production
Q5
HEOS Locale :
HEOS Locale
"Press "
STATUS
" button.
*****
Q6
Restore Version :
RSTR
"Press "
STATUS
" button.
************
Q7
Ether MAC Address :
*Ether MAC
"Press "
STATUS
" button.
******-******
Q8
Wi-Fi MAC Address :
*Wi-Fi MAC
"Press "
STATUS
" button.
******-******
Q9
Bluetooth MAC Address :
*BT MAC Address
"Press "
STATUS
" button.
******-******
W0
Audyssey App Interface Ver :
Audy IFVer:**.**
1.1. Actions
Version information is displayed when the device is started in this mode.
1.2. Starting up
While holding down buttons "
DIMMER
" and "
STATUS
" simultaneously, press the power button to turn
on the power.
then press the "
STATUS
" button to display the information in section 1.3 on the display.
b
The version list is also displayed on GUI while the version is displayed on the display.
1.3. Display Order
Error information(See "1.4. Error display") →
q
Model destination information →
w
Serial Number
→
e
Firmware Package →
r
Main μ -com →
t
Main 1st Boot Loader →
y
DSP →
u
Audio PLD
→
i
Video PLD →
o
GUI SFLASH →
Q0
PIMG →
Q1
HEOS Version →
Q2
HEOS Build →
Q3
HEOS Module
→
Q4
HEOS Conguration →
Q5
HEOS Locale →
Q6
Restore Version →
Q7
Ether Mac Address
→
Q8
WiFi Mac Address →
Q9
BT Mac Address →
W0
Audyssey App Interface Version
