Marantz PM5005 User Manual

Specifications
0
RMS Power output (40 Hz – 20 kHz simultaneous drive of both
channels) :
40 W x 2 (8 Ω/ohms load)
55 W x 2 (4 Ω/ohms load)
0
Total harmonic distortion (40 Hz – 20 kHz simultaneous drive of both
channels, 8 Ω/ohms load) :
0.01 %
0
Output band width (8 Ω/ohms load, 0.06 %) : 10 Hz – 30 kHz
0
Frequency response (CD, 1 W, 8 Ω/ohms load) : 10 Hz – 50 kHz +0 dB, –1 dB
0
Dumping factor (8 Ω/ohms load, 40 Hz – 20 kHz) : 100
0
Input sensitivity/Input impedance
PHONO (MM) : 2.2 mV/47 kΩ/kohms
CD, TUNER, NETWORK, RECORDER : 200 mV/20 kΩ/kohms
0
Maximum allowable PHONO input level (1 kHz) MM : 110 mV
0
RIAA deviation (40 Hz – 20 kHz) : ±0.5 dB
0
S/N (IHF-A, 8 Ω/ohms load)
PHONO (MM) : 83 dB (5 mV input, 1 W output)
CD, TUNER, NETWORK, RECORDER : 103 dB (2 V input, Rated output)
0
Tone Control
BASS (100 Hz) : ±10 dB
TREBLE (10 kHz) : ±10 dB
0
Power requirement : AC 230 V, 50/60 Hz
0
Power consumption (EN60065) : 110 W
0
Power consumption in standby mode : 0.3 W
For the purpose of improvement, the specifications and design are subject to change without notice.
Contents
Connections Playback Settings Tips Appendix
41
Front panel Rear panel
Remote control
unit
Index

Marantz PM5005 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	10 - 50000 Hz
Input sensitivity	200 mV
Audio output channels	2.0 channels
Peak power per channel	40 W
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.05 %
Dynamic power per channel (4 Ohm)	60 W
Dynamic power per channel (8 Ohm)	45 W
RMS power output per channel (4 Ohm)	55 W
AC (power) in	Yes
Audio (L/R) in	6
Audio (L/R) out	2
Headphone outputs	1
Purpose	Home
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	110 W

Weight and Dimensions

Depth	370 mm
Width	440 mm
Height	105 mm
Weight	6700 g
