Marantz PM6005 Service Manual

FRONT PANEL ASSY
Refer to "DISASSEMBLY
1. FRONT PANEL ASSY"
and "EXPLODED VIEW"
POWER SW PWB
(Ref. No. of EXPLODED VIEW : C1)
HEADPHONE PWB
(Ref. No. of EXPLODED VIEW : C2)
FRONT PWB
(Ref. No. of EXPLODED VIEW : C3)
VOLUME PWB
(Ref. No. of EXPLODED VIEW : C4)
MAIN
ASSY
Refer to "DISASSEMBLY
5. MAIN
ASSY
"
and "EXPLODED VIEW"
MAIN PWB ASSY
(Ref. No. of EXPLODED VIEW : C7)
DIGTAL PWB
Refer to "DISASSEMBLY
2. DIGTAL ASSY"
and "EXPLODED VIEW"
DIGTAL PWB
(Ref. No. of EXPLODED VIEW : C10)
POWER TRANS
Refer to "DISASSEMBLY
4. POWER TRANS"
and "EXPLODED VIEW"
POWER TRANS
(Ref. No. of EXPLODED VIEW : C5)
STANDBY PWB
Refer to "DISASSEMBLY
3. STANDBY PWB"
and "EXPLODED VIEW"
STANDBY PWB
(Ref. No. of EXPLODED VIEW : C6)
TOP COVER
DISASSEMBLY
• Disassemble in order of the arrow in the following gure.
• In the case of the re-assembling, assemble it in order of the reverse of the following ow.
• In the case of the re-assembling, observe "attention of assembling".
• If wire bundles are untied or moved to perform adjustment or replace parts etc., be sure to rearrange them neatly as
they were originally bundled or placed afterward.
Otherwise, incorrect arrangement can be a cause of noise generation.
11

Marantz PM6005 Specifications

General

Amplifier class	-
Frequency range	10 - 70000 Hz
Input sensitivity	200 mV
Audio output channels	2.0 channels
Peak power per channel	60 W
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.08 %
RMS power output per channel (8 Ohm)	45 W
AC (power) in	Yes
Audio (L/R) in	5
Audio (L/R) out	1
Speakers connectivity type	RCA
Purpose	Home
Product color	Black
Connectivity technology	Wired
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	155 W

Weight and Dimensions

Depth	370 mm
Width	440 mm
Height	105 mm
Weight	7600 g
