Marantz PM6006 Service Manual

LEVEL / BLOCK DIAGRAM
+30
+20
+10
0
-10
-20
-30
-40
-50
-60
+30
+20
+10
0
-10
-20
-30
-40
-50
-60
SP out:45W/8Ω +25.56dB(18.97V)
Power Amp Gv=24.1dB
Pre Amp Gv=15.4dB
Phono Amp Gv=39.2dB
+1.43dB
-13.97dB
CD:-13.97dB(200mV)
MM:-53.15dB(2.2mV)
[dB] [dB]
R IAA
NFB
TR E BLE
NFB
PHONO
CD
TUNE R
R E COR DE R
IN
R E COR DE R
OUT
S PE AKE R-A
(+)
S PE AKE R-A
(-)
HE ADP HONE
VOLUME
BALANC E
S OUR CE DIR E CT
MUTE
S PE AKE R-B
(+)
S PE AKE R-B
(-)
R E C BUF FE R
BAS S
LINE DE TE CT
LINE DE TE CT
AMP
LOUDNE S S
PR OTE CTION
S PE AKE R
R E LAY
S PE AKE R
R E LAY
HE ADP HONE
R E LAY
PR E AMP
TONE AMP
POWE R AMP
PHONO AMP
ON
OF F
ON
OF F
PHONO B LOCK
LOUDNE S S
BLOC K
PR E AMP B LOCK
TONE AMP BLOC K
MAIN AMP BLOCK
MAIN BLOCK
COAX.
IN
24.576MHz
HDAM
LP F
HDAM
S A2
PCM
MCK
NETWORK
DIGITAL INPUT
BLOCK
OPT.2
IN
OPT.1
IN
INPUT BLOCK PRE AMP BLOCK TONE AMP BLOCK POWER AMP BLOCK
16
Caution in
servicing
Electrical Mechanical Repair Information Updating

Marantz PM6006 Specifications

General

Amplifier class	-
Frequency range	10 - 70000 Hz
Input sensitivity	200 mV
Audio output channels	2.0 channels
Peak power per channel	60 W
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.08 %
RMS power output per channel (8 Ohm)	45 W
AC (power) in	Yes
Audio (L/R) in	5
Audio (L/R) out	1
Speakers connectivity type	RCA
Purpose	Home
Product color	Black
Remote control type	RC003PMCD
Connectivity technology	Wired
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	155 W

Weight and Dimensions

Depth	370 mm
Width	440 mm
Height	105 mm
Weight	7600 g
