3. STANDBY LED ashes while using the unit
(Protection circuit becomes activated)
4. The power turns on but no sound is output
5. Sound is not output by any of the Tuner/CD/Network/Recorder/
Analog input
4.1 STANDBY LED not ashing (no protection operation)
4.2 Mute LED ashes when the volume is increased
(protection circuit operates)
The power on/off LED ashes 0.5 seconds on/0.5 seconds off, the VOLUME turns down and auto-
matically recovers.
Check insertion of each connector.
Check insertion of each connector.
[R3003/R3004](Tuner), [R3007/R3008](CD)
Check the conduction of [R3011/R3012](Net-
work) and [R3015/R3016](Recorder).
Check the voltage
MAIN PCB [U3501] 12pin(-15V), 19pin(+15V)
Repair faulty parts.
Check the voltage of [R3805, R3806, U8101,
U8102], check the solder and surrounding
circuits around [U3501], and repair any faulty
sections.
Check insertion of Input level and each con-
nector.
Broken wire in POWER TRANS [T0001].
Damaged Selector [U3501]
Mute circuit [Q6001-6002, Q7501-7502] faulty
Failure of the power amplier circuit.
Mute circuit
[U1001] faulty
Volume [V5001] faulty.
[C7501-7504] faulty
See within
"2. The power cannot be turned on
(STANDBY LED is lit → light ashes)" (
z
1)
Check the conduction of POWER TRANS
[T0001].
Check the SPEAKER connections, SPEAKER
short circuit and SPEAKER resistance value.
No conduction.
After automatic recovery, if the protection circuit operates
again when the volume is increased again the STANDBY LED
ashes 0.25 seconds on/0.25 seconds off.
It conducts.
It conducts.
P_DWN detection fault.
[U1001] faulty
DC OFFSET DETECT faulty
OVER HEAT DETECT faulty
OVER CURRENT DETECT faulty
Failure of the power amplier circuit.
Damage to power supply circuit
Check the input level, speaker Connection
and speaker resistance value.
OK
OK
