Marantz PM7005 User Manual

Connecting a PC or Mac
By connecting a computer to the USB-DAC port on the rear panel of this unit using a commercially available USB connecting cable, this unit can be used
as a D/A converter. (v p. 30)
.
Ty p e A
USB 2.0 cable
(Sold separately)
Ty p e B
Computer on which the driver software and audio
player software are installed
0
Install the dedicated driver software on the computer to enable communication between the computer and this unit in order to playback high-resolution sound source (DSD
signal or 192 kHz/24 bit PCM signal) audio available on the internet. (v p. 30)
0
Download the driver software from the PM7005 page of the Marantz website.
NOTE
Use a cable that is 3 m or less to connect to the computer.
Contents Connections Playback Settings Tips Appendix
23
Front panel Rear panel
Remote control
unit
Index

Marantz PM7005 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	2.0 channels
Peak power per channel	40 W
Signal-to-Noise Ratio (SNR)	104 dB
Total Harmonic Distortion (THD)	0.02 %
AC (power) in	Yes
Audio (L/R) in	5
USB 2.0 ports quantity	1
Speakers connectivity type	Clamp terminals
Purpose	Home
Product color	Gold, Silver
Volume control	Rotary
Cables included	AC
Connectivity technology	Wired
Power consumption (standby)	0.2 W
Power consumption (typical)	170 W

Weight and Dimensions

Depth	379 mm
Width	440 mm
Height	125 mm
Weight	10000 g
