Marantz PM7005 User Manual

High performance
0
Equipped with a USB-DAC function to support DSD file playback
This unit is equipped with a USB-DAC function that supports DSD
signals and 192 kHz/24 bit PCM signals. You can enjoy high-quality
audio playback from the D/A converter built in to this unit by inputting
PCM signal or DSD signal music files into this unit from a computer via
USB connection.
0
Install the dedicated driver software onto the computer before use.
“Installing the driver software” (v
p. 30)
0
You can use whichever commercially available or downloadable
player software you like to playback files on your computer.
0
Can be used as a D/A convertor
Digital audio signals input from an external device or computer into this
unit can be converted and output as analog signals using this unit’s D/A
converter.
Easy operation
0
Remote control compatible with CD players and network audio
players
The remote control provided with this unit can control Marantz CD
players and network audio players in addition to this unit. (v p. 13)
Contents
Connections Playback Settings Tips Appendix
6
Front panel Rear panel
Remote control
unit
Index

Marantz PM7005 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	2.0 channels
Peak power per channel	40 W
Signal-to-Noise Ratio (SNR)	104 dB
Total Harmonic Distortion (THD)	0.02 %
AC (power) in	Yes
Audio (L/R) in	5
USB 2.0 ports quantity	1
Speakers connectivity type	Clamp terminals
Purpose	Home
Product color	Gold, Silver
Volume control	Rotary
Cables included	AC
Connectivity technology	Wired
Power consumption (standby)	0.2 W
Power consumption (typical)	170 W

Weight and Dimensions

Depth	379 mm
Width	440 mm
Height	125 mm
Weight	10000 g
