Marantz PM8006 - Specifications

Specifications
0
RMS Power output (20 Hz – 20 kHz simultaneous drive of both
channels) :
70 W x 2 (8 Ω/ohms load)
100 W x 2 (4 Ω/ohms load)
0
Total harmonic distortion (20 Hz – 20 kHz simultaneous drive of
both channels, 8 Ω/ohms load) :
0.02 %
0
Output band width (8 Ω/ohms load, 0.06 %) : 5 Hz – 60 kHz
0
Frequency response (CD, 1 W, 8 Ω/ohms load) : 5 Hz – 100 kHz ±3 dB
0
Damping factor (8 Ω/ohms load, 40 Hz – 20 kHz) : 100
0
Input sensitivity/Input impedance
PHONO (MM) :
2.0 mV/47 kΩ/kohms
CD, TUNER, NETWORK, AUX, RECORDER :
220 mV / 20 kΩ/kohms
POWER AMP DIRECT IN :
1.6 V / 15 kΩ/kohms
0
Output voltage/Output impedance
PRE OUT :
1.6 V / 600 Ω/ohms
0
Maximum allowable PHONO input level (1 kHz) MM : 80 mV
0
RIAA deviation (20 Hz – 20 kHz) : ±0.5 dB
0
S/N (IHF-A, 8 Ω/ohms load)
PHONO (MM) :
87 dB (5 mV input, 1 W output)
CD, TUNER, NETWORK, AUX, RECORDER :
106 dB (2 V input, Rated output)
POWER AMP DIRECT IN :
125 dB (Rated output)
