Marantz PM8006 User Manual

Inserting the batteries
1
Remove the rear lid in the direction of the arrow and
remove it.
.
2
Insert two batteries correctly into the battery
compartment as indicated.
.
Batteries
3
Put the rear cover back on.
NOTE
0
To prevent damage or leakage of battery fluid:
0
Do not use a new battery together with an old one.
0
Do not use two different types of batteries.
0
Remove the batteries from the remote control unit if it will not be in use for long
periods.
0
If the battery fluid should leak, carefully wipe the fluid off the inside of the battery
compartment and insert new batteries.
Operating range of the remote control
unit
Point the remote control unit at the remote sensor when operating it.
.
Approx. 23 ft/7 m
30° 30°
Contents
Connections Playback Settings Tips Appendix
5
Front panel Rear panel
Remote control
unit
Index

Marantz PM8006 Specifications

General

Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	2 mV
Audio output channels	2.0 channels
Peak power per channel	70 W
Signal-to-Noise Ratio (SNR)	87 dB
Total Harmonic Distortion (THD)	0.02 %
RMS power output per channel (4 Ohm)	100 W
Product color	Gold, Silver
Volume control	Rotary
Remote control type	RC001PMND
Connectivity technology	Wired
Audio (L/R) in	6
Audio (L/R) out	1
Speaker selector	A / B
Power consumption (standby)	0.2 W
Power consumption (typical)	220 W
Certification	CE, EAC

Weight and Dimensions

Depth	379 mm
Width	440 mm
Height	128 mm
Weight	12000 g
