Marantz SA-7S1f - Page 27

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
1-41
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
001B 99M27AK248410 99M27AK248410 PANEL FRONT PANEL ASSY COLD
002B ns
p
ns
p
PANEL FRONT AL PANEL GOLD HAIR
003B 00M27AK063110 00M27AK063110 ESCUTCHEON ESCUTCHEON LEFT
004B 00M27AK063120 00M27AK063120 ESCUTCHEON ESCUTCHEON R
006B ns
p
ns
p
BADGE MARANTZ BADGE
007B 00M27AK158010 00M27AK158010 WINDOW WINDOW
008B ns
p
ns
p
RING RING FOR POWER SWITCH
009B ns
p
ns
p
LENS LENS FOR IR
010B 00M269J355010 00M269J355010 LENS LENS FOR LED
011B 00M27AK105020 00M27AK105020 CHASSIS FRONT MOLD CHASSIS
017B 00M27AK270120 00M27AK270120 BUTTON BUTTON FOR PLAY
018B 00M27AK270130 00M27AK270130 BUTTON BUTTON FOR STOP
019B 00M27AK270140 00M27AK270140 BUTTON BUTTON FOR PAUSE
020B 00M27AK270150 00M27AK270150 BUTTON BUTTON FOR OPEN/CLOSE
021B 00M27AK270160 00M27AK270160 BUTTON BUTTON FOR FF
024B 00M27AK270180 00M27AK270180 BUTTON BUTTON FOR CLOCK/PHASE/S.MODE
001D 00M340J249110 00M340J249110 PANEL SIDE PANEL LEFT
002D 00M340J249120 00M340J249120 PANEL SIDE PANEL RIGHT
003D 00M340J063130 00M340J063130 ESCUTCHEON SIDE ESCUTCHEON
007D 00M27AK257110 00M27AK257110 LID TOP LID
002G 00M163J057220 00M163J057220 LEG LEG
(
CUPPER
)
029G 00M18AK121010 00M18AK121010 LINK LINK FOR POWER SWITCH
030G 00M27AK112010 00M27AK112010 SHAFT SHAFT FOR POWER SWITCH
031G 00M27AK270110 00M27AK270110 BUTTON BUTTON FOR POWER SWITCH
036B ns
p
ns
p
SHEET SHEET FOR FRONT PANEL TOP
039B ns
p
ns
p
ADHESIVE ADHESIVE FOR POWER RING
910G 00M339J259030 00M339J259030 BUSHING BUSH FOR CINCH TERMINAL
001M ns
p
ns
p
MECHANISM SA-CD MECHA UNIT
007M 00M27AK063130 00M27AK063130 ESCUTCHEON TRAY ESCUTCHEON
008M 00M27AK355010 00M27AK355010 LENS LENS FOR TRAY ESCUTCHEON
009M 00M27AK259110 00M27AK259110 BUSHING BUSH FOR TRAY ESCUTCHEON L
010M 00M27AK259120 00M27AK259120 BUSHING BUSH FOR TRAY ESCUTCHEON R
1000 00M18AK271520 00M18AK271520 UNIT KIT LCD UNIT KIT
1002 00MHQ21202990 00MHQ21202990 DISPLAY LCD WSTN NEGATIVE96X35 TRULY
J001 00MYJ04002550 00MYJ04002550 TERMINAL ! INLET TYPE HF-301
J402 00MYT02010740 00MYT02010740 TERMINAL 1P CINCH JACK
J403 00MYP10002780 00MYP10002780 TERMINAL XLR OUTPUT
(
GOLD PIN WITH GND
)
J452 00MYT02010740 00MYT02010740 TERMINAL 1P CINCH PIN JACK
J453 00MYP10002780 00MYP10002780 TERMINAL XLR OUTPUT
(
GOLD PIN WITH GND
)
JT03 00MYT02011300 00MYT02011300 TERMINAL EW-2560T-LH-B
L003 00MFC50230010 00MFC50230010 FERRITE CORE TFCK-23-11-14
L101 00MFC90280010 00MFC90280010 FERRITE CORE HF70SH28*2*10 FPC FERRITE CORE
L104 00MFC90280010 00MFC90280010 FERRITE CORE HF70SH28*2*10 FPC FERRITE CORE
L801 00MFC50270040 00MFC50270040 FERRITE CORE USB-4 SLEEVE FERRITE CLAMP
L805 00MFC50160060 00MFC50160060 FERRITE CORE FERRITE CORE TFCK-16-8-13
L850 00MFC50270040 00MFC50270040 FERRITE CORE USB-4 SLEEVE FERRITE CLAMP
LH01 F N ns
p
00MTS58601010 TRANSF. # MAIN TRANSF. 100V 50/60HZ
LH01
/
K1G ns
p
00MTS58601030 TRANSF. # MAIN TRANSF. 230V 50/60HZ
LH01
/
N1G 00MTS58601030 00MTS58601030 TRANSF. # MAIN TRANSF. 230V 50/60HZ
LH01
/
U1G ns
p
00MTS58601020 TRANSF. # MAIN TRANSF. 120V 60HZ
LT11 00MFC50230010 00MFC50230010 FERRITE CORE TFCK-23-11-14
PA16 ns
p
ns
p
PWB ASSY AUDIO PWB ASSY
PP16 ns
p
ns
p
PWB ASSY POWER SUPPLY PWB ASSY
PT16 ns
p
ns
p
PWB ASSY FERRITE CORE PWB ASSY
PY16 ns
p
ns
p
PWB ASSY FRONT1 PWB ASSY
PY26 ns
p
ns
p
PWB ASSY FRONT2
(
LED
)
PWB ASSY
PY36 ns
p
ns
p
PWB ASSY FRONT3
(
STAR LED
)
PWB ASSY
W101 ns
p
00MYU25080590 FPC SMCD-25X80-BDX8
(
BL
)
+20
(
BL
)
-P1.0-S4-M
W102 ns
p
00MYU25080590 FPC SMCD-25X80-BDX8
(
BL
)
+20
(
BL
)
-P1.0-S4-M
WY01 ns
p
00MYU22100520 FPC SMCD-22X100-BDX6
(
BL
)
-P1.0-S4-M UL2896
WY05 ns
p
00MYU06080520 FPC SMCD-6X80-BDX6
(
BL
)
-P1.0-S4-M UL2896
PACKING
001T F N ns
p
00M27AK851110 USER GUIDE USER GUIDE SA-7S1
(
F
)
001T
/
K1G ns
p
00M27AK851350 USER GUIDE USER GUIDE SA-7S1
(
K
)
001T
/
N1G 00M27AK851310 00M27AK851310 USER GUIDE USER GUIDE SA-7S1
(
N
)
001T
/
U1G ns
p
00M27AK851250 USER GUIDE USER GUIDE SA-7S1
(
U
)
T001 00MZK27AK0010 00MZK27AK0010 UNIT KIT REMOTE CONTROLLER RC001SA
POS. NO.
