Marantz SA-7S1f - Exploded View and Parts List

1. EXPLODED VIEW AND PARTS LIST
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
LOADER PART LIST
B 00M27AK005510 00M27AK005510 CLAMPER GUIDE CLAMPER ASSY E2A003
C 00M27AK304510 00M27AK304510 MECHANISM LOADER ASSY E2A004
1ns
p
ns
p
CHASSIS MAIN-CHASSIS-ASSY E2A001
2ns
p
ns
p
BRACKET CLAMPER-T M12H A7P085
3ns
p
ns
p
BRACKET GUIDE-CLAMP E2P003
4ns
p
ns
p
MOTOR ASSY MOTOR LOAD C2A003
5ns
p
ns
p
GEAR GEAR-LOAD-2HP C2G029
6ns
p
ns
p
GEAR GEAR 2ND LOAD B9G030
7ns
p
ns
p
GEAR GEAR 3RD LOAD B9G031
8ns
p
ns
p
CHASSIS GUIDE-CHASSIS-L E2G005
9ns
p
ns
p
CHASSIS GUIDE-CHASSIS-R E2G006
10 00M27AK163310 00M27AK163310 TRAY TRAY E2G007
11 ns
p
ns
p
CAM SLIDE-CAM-2H C1G003
12 ns
p
ns
p
ARM ARM-TRV-CHAS-2H C1G004
13 ns
p
ns
p
CLAMPER CLAMPER-H-200T D8G005
14 ns
p
ns
p
CLAMPER CLAMPER-LO E2G002
15 00M27AK051310 00M27AK051310 GUIDE SHAFT-GUIDE-L E2G003
16 00M27AK051320 00M27AK051320 GUIDE SHAFT-GUIDE-R E2G004
17 00M27AK112310 00M27AK112310 SHAFT TRAY-SHAFT E2H002
18 00M27AK058310 00M27AK058310 GEAR TRAY-RACK E2G001
19 ns
p
ns
p
BRACKET RACK-GUIDE E2P001
20 ns
p
ns
p
BUFFER CLAMPER-SHEET E2P002
21 ns
p
ns
p
BRACKET SPG-1 E2P005
22 00M27AK053110 00M27AK053110 COVER COVER E2P007
23 ns
p
ns
p
BRACKET SIDE-PANEL E2P008
24 ns
p
ns
p
BRACKET BRACKET E2P006
25 00M27AK264310 00M27AK264310 BELT BELT LOAD B9G015
26 ns
p
ns
p
PWB ASSY PCB-SW-2H C1P014
27 ns
p
ns
p
CORD CNW-5P C2G094
28 90M-SM000420R 90M-SM000420R SW SW ESE22MH21 S01W204
29 90M-SM000430R 90M-SM000430R SW SW ESE22MH23 S01W205
30 ns
p
ns
p
WASHER PSW2.6X6X0.25C P26C625
31 ns
p
ns
p
BUFFER RUBBER-CUSHION C1G042
32 ns
p
ns
p
SCREW M1.7X2.2 P.H.M.SCREW 3BZ22U3
33
nsp nsp
SCREW M2X3 P.H.M.SCREW 3CS03U3
34 ns
p
ns
p
SCREW M2.6X6 B.H.M.SCREW BDB06K3
35 ns
p
ns
p
SCREW M2.6X6 B.H.M.SCREW BDS06U3
37 ns
p
ns
p
SCREW M2.6×5 F.H.TAPT.SCREW PDS05W3
38 ns
p
ns
p
SCREW M3×8 B.H.M.SCREW BEB08SN
39 ns
p
ns
p
SCREW M3×6 B.H.M.SCREW BEZ06U3
40 ns
p
ns
p
SCREW M2×6 B.H.TAPT.SCREW BCS06U3
41 ns
p
ns
p
SCREW M3-STAD E2H003
42 ns
p
ns
p
BRACKET BOTTOM-L E2P009
43 ns
p
ns
p
BRACKET BOTTOM-R E2P010
45 ns
p
ns
p
CLAMPER NILON BAND
(
80MM
)
M01N122
46 ns
p
ns
p
CUSHION TRAY-CUSHION C2G045
47 ns
p
ns
p
SHEET PET-SHEET-0.2 E2P013
50 ns
p
ns
p
SHEET SHEET-R E2P014
TRAVERSE PART LIST
A 00M27AK304520 00M27AK304520 MECHANISM TRAVERSE ASSY E2A002
51 ns
p
ns
p
CHASSIS ASSY-CHAS-PU-W C2A113
52 ns
p
ns
p
HOLDER HLD-SFT-L-84H C2G008
53 ns
p
ns
p
HOLDER HLD-SFT-R-84H C2G007
54 ns
p
ns
p
HOLDER BASE TILT-W C2G224
55 ns
p
ns
p
PLATE PLATE-TILT-W C2P166
56 ns
p
ns
p
SPRING TILT-SPRING B7S003
57 ns
p
ns
p
SHAFT RAIL C2H001
58 ns
p
ns
p
GUIDE S-GUIDE- BAR-84H C2H002
59 ns
p
ns
p
GEAR RACK-PU-W C2G225
60 ns
p
ns
p
GEAR AS GEAR 2ND B8A005
61 ns
p
ns
p
MECHANISM PICK UP HOP-1200W-B C2G226
62 ns
p
ns
p
SPRING SPRING-RAIL-84H C2P016
63 ns
p
ns
p
SPRING SPG RACK-84H C2S005
64 ns
p
ns
p
MOTOR AS MOTOR FEED-2HP C2A023
65 ns
p
ns
p
MOTOR T/T MOTOR ASSY C2A019
66 ns
p
ns
p
SCREW M2.6X6 BIND S-TIGHT-CR3 BDS06U3
67 ns
p
ns
p
SCREW M2.6X4 BIND S-TIGHT-CR3 BDS04U3
68 ns
p
ns
p
SCREW M2.6X15 FLAT S-TIGHT-CR3 PDS15U3
69 ns
p
ns
p
SCREW MM3X4 HEXAGONAL HOLE CR3 HEA04K3
70 ns
p
ns
p
SCREW M3X8 HEXAGONAL HOLE CR3 HEA08K3
71 ns
p
ns
p
SCREW M1.7X2.2 CR3 3BZ22U3
72 00M27AK130310 00M27AK130310 DAMPER DAMPER-IDLE C2G083
73 ns
p
ns
p
WASHER PSW2X4X0.25C P21C425
POS. NO.
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
