NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
1-44
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
AUDIO PWB PA16
(
00MWI27AK201-
)
PA16 C101 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C102 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C103 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C104 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C105 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C106 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C107 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C108 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C109 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C110 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C111 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C112 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C113 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C114 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C115 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C116 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C117 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C118 ns
p
00MDK96681300 CER. CAP. 680PF
(
GR39
)
PA16 C119 ns
p
00MDD91060300 CER. CAP. 6 PF +-0.5 PF CH 50V GR39
PA16 C120 ns
p
00MDD99030300 CER. CAP. 3 PF +-0.1 PF CJ 50V
PA16 C121 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C122 00D2574015901 00D2574015901 CER. CAP. CE67C1C330MT
(
PXA
)
PA16 C123 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C124 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C125 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C126 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C127 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C128 00MEY10601620 00MEY10601620 ELECT CAP. 10UF/ 16V
PA16 C129 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C130 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C133 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C134 00MEY10700620 00MEY10700620 ELECT CAP. 100UF/6.3V
PA16 C135 ns
p
00MDK96105200 CER. CAP. 1UF B 6.3V
PA16 C137 ns
p
00MDK96682300 CER. CAP. 6800PF
(
GR39
)
PA16 C138 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C139 00D2574015901 00D2574015901 CER. CAP. CE67C1C330MT
(
PXA
)
PA16 C140 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C141 00MEY10700620 00MEY10700620 ELECT CAP. 100UF/6.3V
PA16 C142 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C143 00MEY22600620 00MEY22600620 ELECT CAP. 22UF/6.3V
PA16 C144 ns
p
00MDD91100300 CER. CAP. 10 PF +-0.5 PF CH 50V GR39
PA16 C145
/
U1G ns
p
00MDD95101300 CER. CAP. 100 PF +-5% CG 50V GR39
PA16 C146
/
U1G ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C147
/
U1G ns
p
00MDD95101300 CER. CAP. 100 PF +-5% CG 50V GR39
PA16 C148 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C149 00MEY10601620 00MEY10601620 ELECT CAP. 10UF/ 16V
PA16 C150 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C151 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C152 00D2574015901 00D2574015901 CER. CAP. CE67C1C330MT
(
PXA
)
PA16 C153 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C154 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C155 00MEY10700620 00MEY10700620 ELECT CAP. 100UF/6.3V
PA16 C156 ns
p
00MOA47701620 ELECT CAP. 470UF 16V M RA-2
PA16 C157 ns
p
00MDD95101300 CER. CAP. 100 PF +-5% CG 50V GR39
PA16 C159
/
U1G ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C160 ns
p
00MDD95101300 CER. CAP. 100 PF +-5% CG 50V GR39
PA16 C161 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C162 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C163 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C164 ns
p
00MDK96104200 CER. CAP. 0.1 UF +-10% B 10V
PA16 C165 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C166 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C167 00MEY10700620 00MEY10700620 ELECT CAP. 100UF/6.3V
PA16 C168 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C169 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PA16 C170 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
POS. NO.
