Marantz SA-7S1f - Page 35

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
1-49
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
PA16 Q377 00MHX328731B0 00MHX328731B0 CHIP TRS. 2SC2873
(
Y
)
PA16 Q378 00MHX113121B0 00MHX113121B0 CHIP TRS. 2SA1312
(
B
)
PA16 Q379 00MHX113121B0 00MHX113121B0 CHIP TRS. 2SA1312
(
B
)
PA16 Q380 00MHX333241B0 00MHX333241B0 CHIP TRS. 2SC3324
(
B
)
PA16 Q381 00MHF201701H0 00MHF201701H0 F.E.T. 2SK170 V LANK
PA16 Q382 00MHF100741H0 00MHF100741H0 F.E.T. 2SJ74 V LANK
PA16 Q401 00MHF203891A0 00MHF203891A0 F.E.T. 2SK389FM-BL
PA16 Q402 00MHX328731B0 00MHX328731B0 CHIP TRS. 2SC2873
(
Y
)
PA16 Q403 00MHX113121B0 00MHX113121B0 CHIP TRS. 2SA1312
(
B
)
PA16 Q404 00MHX113121B0 00MHX113121B0 CHIP TRS. 2SA1312
(
B
)
PA16 Q405 00MHX333241B0 00MHX333241B0 CHIP TRS. 2SC3324
(
B
)
PA16 Q409 00MHX113121B0 00MHX113121B0 CHIP TRS. 2SA1312
(
B
)
PA16 Q410 00MHX113121B0 00MHX113121B0 CHIP TRS. 2SA1312
(
B
)
PA16 Q412 00MHX333241B0 00MHX333241B0 CHIP TRS. 2SC3324
(
B
)
PA16 Q413 00MHX333241B0 00MHX333241B0 CHIP TRS. 2SC3324
(
B
)
PA16 Q414 00MHT327052A0 00MHT327052A0 TRS. 2SC2705 O OR Y
PA16 Q415 00MHT111452A0 00MHT111452A0 TRS. 2SA1145 O OR Y
PA16 Q426 00MHF203891A0 00MHF203891A0 F.E.T. 2SK389FM-BL
PA16 Q427 00MHX328731B0 00MHX328731B0 CHIP TRS. 2SC2873
(
Y
)
PA16 Q428 00MHX113121B0 00MHX113121B0 CHIP TRS. 2SA1312
(
B
)
PA16 Q429 00MHX113121B0 00MHX113121B0 CHIP TRS. 2SA1312
(
B
)
PA16 Q430 00MHX333241B0 00MHX333241B0 CHIP TRS. 2SC3324
(
B
)
PA16 Q434 00MHX113121B0 00MHX113121B0 CHIP TRS. 2SA1312
(
B
)
PA16 Q435 00MHX113121B0 00MHX113121B0 CHIP TRS. 2SA1312
(
B
)
PA16 Q437 00MHX333241B0 00MHX333241B0 CHIP TRS. 2SC3324
(
B
)
PA16 Q438 00MHX333241B0 00MHX333241B0 CHIP TRS. 2SC3324
(
B
)
PA16 Q439 00MHT327052A0 00MHT327052A0 TRS. 2SC2705 O OR Y
PA16 Q440 00MHT111452A0 00MHT111452A0 TRS. 2SA1145 O OR Y
PA16 Q451 00MHF203891A0 00MHF203891A0 F.E.T. 2SK389FM-BL
PA16 Q452 00MHX328731B0 00MHX328731B0 CHIP TRS. 2SC2873
(
Y
)
PA16 Q453 00MHX113121B0 00MHX113121B0 CHIP TRS. 2SA1312
(
B
)
PA16 Q454 00MHX113121B0 00MHX113121B0 CHIP TRS. 2SA1312
(
B
)
PA16 Q455 00MHX333241B0 00MHX333241B0 CHIP TRS. 2SC3324
(
B
)
PA16 Q459 00MHX113121B0 00MHX113121B0 CHIP TRS. 2SA1312
(
B
)
PA16 Q460 00MHX113121B0 00MHX113121B0 CHIP TRS. 2SA1312
(
B
)
PA16 Q462 00MHX333241B0 00MHX333241B0 CHIP TRS. 2SC3324
(
B
)
PA16 Q463 00MHX333241B0 00MHX333241B0 CHIP TRS. 2SC3324
(
B
)
PA16 Q464 00MHT327052A0 00MHT327052A0 TRS. 2SC2705 O OR Y
PA16 Q465 00MHT111452A0 00MHT111452A0 TRS. 2SA1145 O OR Y
PA16 Q476 00MHF203891A0 00MHF203891A0 F.E.T. 2SK389FM-BL
PA16 Q477 00MHX328731B0 00MHX328731B0 CHIP TRS. 2SC2873
(
Y
)
PA16 Q478 00MHX113121B0 00MHX113121B0 CHIP TRS. 2SA1312
(
B
)
PA16 Q479 00MHX113121B0 00MHX113121B0 CHIP TRS. 2SA1312
(
B
)
PA16 Q480 00MHX333241B0 00MHX333241B0 CHIP TRS. 2SC3324
(
B
)
PA16 Q484 00MHX113121B0 00MHX113121B0 CHIP TRS. 2SA1312
(
B
)
PA16 Q485 00MHX113121B0 00MHX113121B0 CHIP TRS. 2SA1312
(
B
)
PA16 Q487 00MHX333241B0 00MHX333241B0 CHIP TRS. 2SC3324
(
B
)
PA16 Q488 00MHX333241B0 00MHX333241B0 CHIP TRS. 2SC3324
(
B
)
PA16 Q489 00MHT327052A0 00MHT327052A0 TRS. 2SC2705 O OR Y
PA16 Q490 00MHT111452A0 00MHT111452A0 TRS. 2SA1145 O OR Y
PA16 Q601 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PA16 Q602 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PA16 Q603 00MHX207982A0 00MHX207982A0 CHIP TRS. 2SB798
(
DL,DK
)
PA16 Q841 00MHT41415100 00MHT41415100 TRS. ! TRANSISTOR 2SD1415
PA16 Q842 00MHF202461C0 00MHF202461C0 F.E.T. 2SK246
(
GR
)
PA16 Q851 00MHT41415100 00MHT41415100 TRS. ! TRANSISTOR 2SD1415
PA16 Q852 00MHT21020100 00MHT21020100 TRS. ! 2SB1020
PA16 Q853 00MHF202461C0 00MHF202461C0 F.E.T. 2SK246
(
GR
)
PA16 Q854 00MHF202461C0 00MHF202461C0 F.E.T. 2SK246
(
GR
)
PA16 Q855 00MHT322402A0 00MHT322402A0 TRS. 2SC2240 GR OR BL
PA16 Q856 00MHT109702A0 00MHT109702A0 TRS. 2SA970
(
GR
)
OR
(
BL
)
PA16 QN05 00MHC3851209F 00MHC3851209F IC ! NJM78M12FA
PA16 QN07 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PA16 QN08 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PA16 QN09 00MHX207982A0 00MHX207982A0 CHIP TRS. 2SB798
(
DL,DK
)
PA16 QN10 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PA16 R102 ns
p
00MNN05101610 CHIP RES. 100 OHM +-5% 1/16W
