Marantz SA-7S1f - Page 43

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
1-57
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
PY16 XY61 00MFQ01605120 00MFQ01605120 CER. VIB. CSTCE16M0V53-R0
PY16 ZF01 00MHW10004210 00MHW10004210 PHOTO UNIT RPM6936-V4
(
IR SENSOR
)
FRONT2
(
LED
)
PWB PY26
(
00MWG27AK103-
)
PY26 CY23 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PY26 CY24 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PY26 CY25 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PY26 CY26 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PY26 DY23 00MHI10042080 00MHI10042080 L.E.D. SECU1E01C
PY26 DY24 00MHI10042080 00MHI10042080 L.E.D. SECU1E01C
PY26 DY25 00MHI10042080 00MHI10042080 L.E.D. SECU1E01C
PY26 DY26 00MHI10107210 00MHI10107210 L.E.D. SML-010VTT86
PY26 RY47 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PY26 RY48 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PY26 RY49 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
FRONT3
(
STAR LED
)
PWB PY36 00MWG27AK104-
)
PY36 CY27 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PY36 DY29 00MHI10042080 00MHI10042080 L.E.D. SECU1E01C
PY36 JY09 00MYJ06008830 00MYJ06008830 JACK 03JQ-ST 3P
(
YOKO
)
PY36 RY53 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
