Marantz SA-7S1f - Page 82

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
3-45
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
1U-3648B C-749 00D2590015901 00D2590015901 EMI FILTER NFM41CC223R2A3L +C
1U-3648B C-750 00D2590015901 00D2590015901 EMI FILTER NFM41CC223R2A3L +C
1U-3648B C-751 ns
p
00D2570512903 CHIP CAP. CK73F1E104ZT +1608
1U-3648B C-752 ns
p
00D2570512903 CHIP CAP. CK73F1E104ZT +1608
1U-3648B C-753 ns
p
00D2570512903 CHIP CAP. CK73F1E104ZT +1608
1U-3648B C-764 ns
p
00D2570512903 CHIP CAP. CK73F1E104ZT +1608
1U-3648B CX052 ns
p
ns
p
CONN. 5P PH CON.BASE
(
L
)
+REF
1U-3648B CX131 ns
p
ns
p
CONN. 13P FFC BASE
(
FMNSMT
)
+REF
1U-3648B CX151 ns
p
ns
p
CONN. 15P FFC BASE
(
P=1.0
)
L +REF
1U-3648B CX241 ns
p
ns
p
CONN. 24P FFC BASE
(
FLZ-SM1 +REF
1U-3648B CY082 ns
p
ns
p
CONN. 8P PH CON.BASE
(
L
)
+REF
1U-3648B CY251 ns
p
ns
p
CONN. 25P FFC BASE
(
FMNSMT
)
+REF
1U-3648B CY252 ns
p
ns
p
CONN. 25P FFC BASE
(
FMNSMT
)
+REF
1U-3648B D-501 00D2760778900 00D2760778900 DIODE 1SS300-TE85L +C
1U-3648B D-701 00D2760717903 00D2760717903 DIODE 1SS355 TE-17 +C
1U-3648B D-702 00D2760717903 00D2760717903 DIODE 1SS355 TE-17 +C
1U-3648B D-703 00D2760717903 00D2760717903 DIODE 1SS355 TE-17 +C
1U-3648B D-704 00D2760717903 00D2760717903 DIODE 1SS355 TE-17 +C
1U-3648B D-731 00D2760717903 00D2760717903 DIODE 1SS355 TE-17 +C
1U-3648B FB401 00D2350136907 00D2350136907 INDUCTOR FBMJ1608HS280NT +1608
1U-3648B FB402 00D2350136907 00D2350136907 INDUCTOR FBMJ1608HS280NT +1608
1U-3648B FB501 ns
p
00D2472005903 CHIP RES. RM73B--101JT +1608
1U-3648B FB502 ns
p
00D2472005903 CHIP RES. RM73B--101JT +1608
1U-3648B FB503 00D2350160902 00D2350160902 INDUCTOR FB M J2125HM330-T +C
1U-3648B FB504 00D2350160902 00D2350160902 INDUCTOR FB M J2125HM330-T +C
1U-3648B FB505 00D2350160902 00D2350160902 INDUCTOR FB M J2125HM330-T +C
1U-3648B FB506 00D2350130903 00D2350130903 INDUCTOR CHIP EMIFIL
(
11A121
)
+1608
1U-3648B FB507 00D2350130903 00D2350130903 INDUCTOR CHIP EMIFIL
(
11A121
)
+1608
1U-3648B FB703 00D2350136907 00D2350136907 INDUCTOR FBMJ1608HS280NT +1608
1U-3648B FB704 00D2350160902 00D2350160902 INDUCTOR FB M J2125HM330-T +C
1U-3648B FB705 00D2350160902 00D2350160902 INDUCTOR FB M J2125HM330-T +C
1U-3648B FB706 00D2350136907 00D2350136907 INDUCTOR FBMJ1608HS280NT +1608
1U-3648B FB707 00D2350160902 00D2350160902 INDUCTOR FB M J2125HM330-T +C
1U-3648B FB708 00D2350160902 00D2350160902 INDUCTOR FB M J2125HM330-T +C
1U-3648B IC401 00D2623217003 00D2623217003 IC CXD2753R +C
1U-3648B IC402 00D2622875006 00D2622875006 IC 16M SDRAM
(
TSOP
)
-7/8 +C
1U-3648B IC403 00D2623195905 00D2623195905 IC AD8062-SO8 +C
1U-3648B IC404 00D2623282009 00D2623282009 IC EPM3128ATC100-10N
(
HARMONY-8LI
)
1U-3648B IC405 00D2623203907 00D2623203907 IC TC7SHU04F-TE85L +REF
1U-3648B IC406 00D2623203907 00D2623203907 IC TC7SHU04F-TE85L +REF
1U-3648B IC501 00D2623219001 00D2623219001 IC CXD1881AR/BR +C
1U-3648B IC502 00D2623218002 00D2623218002 IC CXD1885Q +C
1U-3648B IC503 00D2623409002 00D2623409002 IC MSM51V18165F-50TSK-7
1U-3648B IC505 00D2631109909 00D2631109909 IC AN8471SA +C
1U-3648B IC507 00D2621782909 00D2621782909 IC TC7S08FTE85L +C
1U-3648B IC508 00D2623221002 00D2623221002 IC FAN8042 +C
1U-3648B IC701 00D2631079903 00D2631079903 IC BA033FP +C
1U-3648B IC702 00D2631079903 00D2631079903 IC BA033FP +C
1U-3648B IC703 00D2622977904 00D2622977904 IC BA18BC0FP-E2 +C
1U-3648B IC704 00D2631182900 00D2631182900 IC NJM2391DL1-26-TE1 +REF
1U-3648B IC731 243010004608M 243010004608M U-PRO M3062LFGPGP-MZ0723
1U-3648B IC732 00D2623659904 00D2623659904 IC IDT71V124SA12TYG8
1U-3648B IC733 00D2623206904 00D2623206904 IC S-80843CLNB-B64-T2 +C
1U-3648B IC734 00D2623197903 00D2623197903 IC TC74VHC74FT-EL +REF
1U-3648B IC735 00D2623200900 00D2623200900 IC TC74VHC00FT-EL +REF
1U-3648B IC736 00D2623198902 00D2623198902 IC TC74VHC157FT-EL +REF
1U-3648B IC737 00D2623388903 00D2623388903 IC AT24C04AN-10SI-1.8 +REF
1U-3648B R-414 ns
p
00D2472009983 CHIP RES. RM73B--103JT +1608
1U-3648B R-415 ns
p
00D2472009983 CHIP RES. RM73B--103JT +1608
1U-3648B R-416 ns
p
00D2472009983 CHIP RES. RM73B--103JT +1608
1U-3648B R-417 ns
p
00D2472009983 CHIP RES. RM73B--103JT +1608
1U-3648B R-418 ns
p
00D2472009983 CHIP RES. RM73B--103JT +1608
1U-3648B R-419 ns
p
00D2472009983 CHIP RES. RM73B--103JT +1608
1U-3648B R-420 ns
p
00D2472009983 CHIP RES. RM73B--103JT +1608
1U-3648B R-421 ns
p
00D2472009983 CHIP RES. RM73B--103JT +1608
1U-3648B R-422 ns
p
00D2472009983 CHIP RES. RM73B--103JT +1608
1U-3648B R-423 ns
p
00D2472008968 CHIP RES. RM73B--332JT +1608
