NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
3-49
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
1U-3648B R-753 ns
p
00D2472007943 CHIP RES. RM73B--102JT +1608
1U-3648B R-754 ns
p
00D2472007943 CHIP RES. RM73B--102JT +1608
1U-3648B R-762 ns
p
00D2472009983 CHIP RES. RM73B--103JT +1608
1U-3648B R-763 ns
p
00D2472010969 CHIP RES. RM73B--223JT +1608
1U-3648B R-766 ns
p
00D2472010969 CHIP RES. RM73B--223JT +1608
1U-3648B R-767 ns
p
00D2472003989 CHIP RES. RM73B--330JT +1608
1U-3648B R-768 ns
p
00D2472003989 CHIP RES. RM73B--330JT +1608
1U-3648B R-769 ns
p
00D2472003989 CHIP RES. RM73B--330JT +1608
1U-3648B R-770 ns
p
00D2472003989 CHIP RES. RM73B--330JT +1608
1U-3648B R-771 ns
p
00D2472003989 CHIP RES. RM73B--330JT +1608
1U-3648B R-772 ns
p
00D2472003989 CHIP RES. RM73B--330JT +1608
1U-3648B R-773 ns
p
00D2472003989 CHIP RES. RM73B--330JT +1608
1U-3648B R-774 ns
p
00D2472003989 CHIP RES. RM73B--330JT +1608
1U-3648B RA401 ns
p
00D2479003908 CHIP RES. MNR14=220JE0AB +C
1U-3648B RA402 ns
p
00D2479003908 CHIP RES. MNR14=220JE0AB +C
1U-3648B RA501 ns
p
00D2479007917 CHIP RES. MNR14=103JE0 +C
1U-3648B RA502 ns
p
00D2479007917 CHIP RES. MNR14=103JE0 +C
1U-3648B RA503 ns
p
00D2479007917 CHIP RES. MNR14=103JE0 +C
1U-3648B RA504 ns
p
00D2479007917 CHIP RES. MNR14=103JE0 +C
1U-3648B TR511 00D2720166905 00D2720166905 TRS. 2SB798
(
DL/DK
)
-T1 +C
1U-3648B TR512 00D2720166905 00D2720166905 TRS. 2SB798
(
DL/DK
)
-T1 +C
1U-3648B X-731 00D3990887903 00D3990887903 X'TAL CSTCE16MOV53-R0 +2125
TRAY DRIVE PWB PM16
(
00MWG27AK801-
)
PM16 CM01 00D2574010906 00D2574010906 ELECT CAP. EMV-160ADA101MH63G
(
100UF/16V
)
PM16 CM02 ns
p
00D2570512903 CHIP CAP. GRM39F104Z16 0.1UF MURATA
PM16 CM04 ns
p
00D2570512903 CHIP CAP. GRM39F104Z16 0.1UF MURATA
PM16 CM05 00D2544465921 00D2544465921 ELECT CAP. EMV-160ADA100MD55G
(
10UF/16V
)
PM16 CM06 ns
p
00D2570512903 CHIP CAP. GRM39F104Z16 0.1UF MURATA
PM16 CM07 00D2544471902 00D2544471902 ELECT CAP. EMV-350ADA4R7MD55G
(
4.7UF/35V
)
PM16 JM01 ns
p
ns
p
CONN. S5B-PH-SM4-TB
(
LF
)(
SN
)
PM16 JM02 ns
p
ns
p
CONN. S5B-PH-SM4-TB
(
LF
)(
SN
)
PM16 JM03 ns
p
ns
p
CONN. 13FMN-SMT-A-TF
(
LF
)(
SN
)
PM16 JM04 ns
p
ns
p
CONN. S4B-PH-SM4-TB
(
LF
)(
SN
)
PM16 QM01 00D2631011903 00D2631011903 IC NJM3414AM-TE DUAL
PM16 QM02 00D2720166905 00D2720166905 TRS. 2SB798-T1
(
DL OR DK
)
PM16 QM03 00D2740204902 00D2740204902 TRS. 2SD999-T1
(
CL OR CM
)
PM16 QM04 00D2740204902 00D2740204902 TRS. 2SD999-T1
(
CL OR CM
)
PM16 QM05 00D2720166905 00D2720166905 TRS. 2SB798-T1
(
DL OR DK
)
PM16 QM06 00D2730470908 00D2730470908 TRS. 2SC4116-Y OR GR-TE85L
PM16 QM07 00D2730470908 00D2730470908 TRS. 2SC4116-Y OR GR-TE85L
PM16 RM01 ns
p
00D2472011968 CHIP RES. RPC05T-563J
(
56K OHM +-5% 1/10W
)
PM16 RM02 ns
p
00D2472012925 CHIP RES. RPC05T-104J
(
100K OHM +-5% 1/10W
)
PM16 RM03 ns
p
00D2472012925 CHIP RES. RPC05T-104J
(
100K OHM +-5% 1/10W
)
PM16 RM04 ns
p
00D2472012925 CHIP RES. RPC05T-104J
(
100K OHM +-5% 1/10W
)
PM16 RM05 ns
p
00D2472011968 CHIP RES. RPC05T-563J
(
56K OHM +-5% 1/10W
)
PM16 RM06 ns
p
00D2472006986 CHIP RES. RPC05T-561J
(
560 OHM +-5% 1/10W
)
PM16 RM07 ns
p
00D2472006960 CHIP RES. RPC05T-471J
(
470 OHM +-5% 1/10W
)
PM16 RM08 ns
p
00D2472011942 CHIP RES. RPC05T-473J
(
47K OHM +-5% 1/10W
)
PM16 RM09 ns
p
00D2472011942 CHIP RES. RPC05T-473J
(
47K OHM +-5% 1/10W
)
PM16 RM10 ns
p
00D2472010969 CHIP RES. RPC05T-223J
(
22K OHM +-5% 1/10W
)
PM16 RM11 ns
p
00D2472012925 CHIP RES. RPC05T-104J
(
100K OHM +-5% 1/10W
)
PM16 RM12 ns
p
00D2472008926 CHIP RES. RPC05T-222J
(
2.2K OHM +-5% 1/10W
)
PM16 RM13 ns
p
00D2472008926 CHIP RES. RPC05T-222J
(
2.2K OHM +-5% 1/10W
)
PM16 RM15 ns
p
00D2472006986 CHIP RES. RPC05T-561J
(
560 OHM +-5% 1/10W
)
PM16 RM16 ns
p
00D2472006960 CHIP RES. RPC05T-471J
(
470 OHM +-5% 1/10W
)
PM16 RM17 ns
p
00D2472006960 CHIP RES. RPC05T-471J
(
470 OHM +-5% 1/10W
)
PM16 RM18 ns
p
00D2472001949 CHIP RES. RPC05T-3R3J
(
3.3 OHM +-5% 1/10W
)
PM16 RM19 ns
p
00D2472001949 CHIP RES. RPC05T-3R3J
(
3.3 OHM +-5% 1/10W
)
PM16 RM20 ns
p
00D2472001949 CHIP RES. RPC05T-3R3J
(
3.3 OHM +-5% 1/10W
)
PM16 RM21 ns
p
00D2472001949 CHIP RES. RPC05T-3R3J
(
3.3 OHM +-5% 1/10W
)
PM16 RM22 ns
p
00D2472009983 CHIP RES. RPC05T-103J
(
10K OHM +-5% 1/10W
)
PM16 RM23 ns
p
00D2472007943 CHIP RES. RPC05T-102J
(
1K OHM +-5% 1/10W
)
