5110
3X6( M)
SYMBOL
+B.H.M.SCREW
+B.H.TAP TITE SCREWW/WASHER
+B. H. TAP TI TE SCREW( B TYPE)
+B.H.M.SCREW(W/WASHER/SP WASHER)
+H.H.TAPT.BOLTS WITH FLANGE(S TITE)
5110
5126
5128
5149
5204
5411
5128
4X35( U)
MN5 1
5128
3X8( M)
008L
5110
3X6( M)
5128
3X8( M)
006Lx4
5149
3X12( M)
5128
3X8( M)
5110
4X8( U)
012L
002Lx4
P794
TEMP- SENSOR
3CH PO- AMP
013Lx4
5110
3X6( M)
5110
3X6( M)
P794
3CH POWER AMP
P704
2CH POWER AMP
P754
3CH POWER TR
P774
001L
5149
3X15( M)
013Lx4
015L
5110
3X8( U)
007L
009Lx4
5128
3X8( M)
5110
3X6( M)
5110
3X6( M)
5149
3X12( M)
5149
3X15( M)
5128
3X8( M)
005L
5149
3X12( U)
5110
3X8( A)
009C
5128
3X8( M)
5126
3X8( U)
001C
002C
004C
001C
003C
006C
014C
007C
PU94
008C
015Cx2
5128
3X8( M)
55 56
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
001B GOLD FRONT AL PANEL KIT GL 322J248510
001B BLACK FRONT AL PANEL KIT BL 322J248500
002B GOLD 9965 000 01780 FRONT AL PANEL GL 322J248110
002B BLACK 9965 000 01780 FRONT AL PANEL BL 322J248010
003B GOLD 9965 000 01781 FRONT MOULD PANEL GL 300J248150
003B BLACK 9965 000 01781 FRONT MOULD PANEL BL 300J248050
005B GOLD 9965 000 01785 WINDOW FL GL 300J158110
005B BLACK 9965 000 01785 WINDOW FL BL 300J158010
006B 9965 000 01794 LENS FUNCTION LED 300J355010
007B GOLD 9965 000 01795 BUTTON GYRO SIDE
FUNCTION GL
300J270120
007B BLACK 9965 000 01795 BUTTON GYRO SIDE
FUNCTION BL
300J270020
008B GOLD 9965 000 01796 ESCUTCHEON CORNER L
SIDE GL
322J063110
008B BLACK 9965 000 01796 ESCUTCHEON CORNER L
SIDE BL
322J063010
010B GOLD 9965 000 01797 ESCUTCHEON CORNER R
SIDE GL
322J063120
010B BLACK 9965 000 01797 ESCUTCHEON CORNER R
SIDE BL
322J063010
012B GOLD 4822 381 12016 LENS IR GL 256J355030
012B BLACK 4822 381 12016 LENS IR BL 256J355040
013B 4822 381 11677 LENS POWER LED 230K355020
014B 4822 462 10955 BUFFER DOOR 446T056010
015B GOLD 9965 000 01798 BUTTON FUNCTION GL 300J270110
015B BLACK 9965 000 01798 BUTTON FUNCTION BL 300J270010
016B GOLD 9965 000 01799 ARM DOOR HINGE L SIDE GL 300J002110
016B BLACK 9965 000 01799 ARM DOOR HINGE L SIDE BL 300J002010
017B GOLD 9965 000 01800 ARM DOOR HINGE R SIDE GL 300J002120
017B BLACK 9965 000 01800 ARM DOOR HINGE R SIDE BL 300J002020
018B 9965 000 01801 SHAFT DOOR 300J112010
021B 4822 529 10215 DAMPER DOOR 391H130030
023B GOLD 9965 000 01802 DOOR PANEL GL 322J162110
023B BLACK 9965 000 01802 DOOR PANEL BL 322J162010
026B 4822 526 20213 MAGNET DOOR 271K305500
028B WINDOW MASK SHEET L 300J303010
029B WINDOW MASK SHEET R 300J303020
030B 9965 000 01803 SPRING DOOR ESD 300J115010
040B GOLD 9965 000 01804 KNOB MASTER GL 300J154210
040B BLACK 9965 000 01804 KNOB MASTER BL 300J154010
041B GOLD 4822 410 11276 BUTTON POWER GL 176J270150
041B BLACK 4822 410 11276 BUTTON POWER BL 176J270050
042B 4822 404 21012 JOINT POWER BUTTON 025J125010
043B 4822 256 92097 HOLDER FL 183J271020
044B 4822 459 11158 STICKER FL ADHESIVE TAPE 056J122010
049B 4822 532 21196 FLAT WASHER 54110149A0
057B MASK IR 300J303030
058B GOLD ESCUTCHEON TOP COVER
SPACER GL
322J063130
058B BLACK ESCUTCHEON TOP COVER
SPACER BL
322J063030
001C GOLD 4822 410 11676 ESCUTCHEON GYRO
UP DOWN GL
290J063110
001C BLACK 4822 410 11676 ESCUTCHEON GYRO
UP DOWN BL
290J063010
002C GOLD 9965 000 01396 RUBBER RING GYRO GL 290J066110
002C BLACK 9965 000 01396 RUBBER RING GYRO BL 290J066010
003C 9965 000 01397 FLYWHEEL GYRO BASE 290J273110
006C 9965 000 01398 SHAFT GYRO MAIN 290J112010
009C RETAINER GYRO UPPER 290J104050
014C 9965 000 01805 SHAFT GYRO SHAFT
SUSTAINER UNDER
300J112020
015C WASHER FOR UNDER SIDE 59071102G0
001D GOLD 9965 000 01806 LID TOP COVER GL 322J257110
001D BLACK 9965 000 01806 LID TOP COVER BL 322J257010
002D GOLD SCREW TOP COVER GL 323S010040
002D BLACK SCREW TOP COVER BL 323S010050
003D GOLD 4822 502 14613 SCREW SIDE GL 258S010020
003D BLACK 4822 502 14613 SCREW SIDE BL 258S010010
004D GOLD 9965 000 01807 SIDE PANEL L GL 322J249110
004D BLACK 9965 000 01807 SIDE PANEL L BL 322J249010
005D GOLD 9965 000 01808 SIDE PANEL R GL 322J249120
005D BLACK 9965 000 01808 SIDE PANEL R BL 322J249020
006D GOLD 9965 000 01809 PERFORATED SIDE NET GL 322J003110
006D BLACK 9965 000 01809 PERFORATED SIDE NET BL 322J003010
055G 4822 462 42134 LEG FRONT GOLD AL CAP 291K057010
056G 4822 462 42134 LEG REAR GOLD AL CAP 291K057010
089G T.L. WASHER 54050400M0
014K BUSHING SPK.TERMINAL CAP
UL 94V-1
227J259020
015K BUSHING SPK.TERMINAL CAP
T10336 94HB
227J259
JL21
SHOTE PLUG SHORT PIN YQ01000080
JL25 PRE OUT - MAIN IN
J001 9965 000 01313 JACK 2P AC INLET PWI1910-H YJ04002440
L001 /K MAINS TRANSF. 220V 50Hz TS42002080
L001 /N,/S 9965 000 01778 MAINS TRANSF. 230V 50Hz TS42002090
L001 /U MAINS TRANSF. 120V 60Hz TS42002100
L002 /K MAINS TRANSF.
220V 50/60Hz
TS17205090
L002 /N,/S 9965 000 01779 MAINS TRANSF.
230V 50/60Hz
TS17205100
L002 /U MAINS TRANSF. 120V 60Hz TS16404120
L003 /N,/S,/U FERRITE CORE TFCK-25-15-12 FC50250020
L004 4822 526 10691 FERRITE CORE
TFCK-16-8-13 FOR WL01
FC50160030
L005 4822 526 10691 FERRITE CORE FE CORE
TFCK-16-8-13 FOR WY04
FC50160030
PACKING
001T /K,/S USER GUIDE 322J851310
001T /N 9965 000 01810 USER GUIDE 322J851350
001T /U USER GUIDE 322J851250
Z001 /K,/S REMOTE COMMANDER
RC-18SR
ZK300J0010
Z007 /K MAINS CORD CCEE 2.5A 250V ZC01803090
Z007 /N,/S 4822 321 11439 MAINS CORD 2P 10A 250V
CLASS2
ZC01803080
Z007 /U MAINS CORD 125V 13A UL ZC01802100
Z008 /S MAINS CORD 10A 250V
HONG KONG
ZC01804070
NOT STANDARD SPARE
PARTS
001S /U PACKING CASE 322J801010
002S /U CUSHION L SIDE 300J809010
003S /U CUSHION R SIDE 300J809020
Z003 /K,/N,/S FM ANTENNA 931222R ZA02800020
Z003 /U FM EXT ANTENNA ZA02000070
Z004 LOOP ANTENNA LA-700HB LA00055010
Z005 /U PLUG ANTENNA ADAPTOR YP90000310
Z006 /K JACK AC ADAPTER S-I6116 YJ04001240
