Connecting a external power amplifier
•You can use this unit as a pre-amp by connecting a commercially available power amp to the PRE OUT
connector. Adding a power amp to each of the channels provides an even greater sound presence.
•Select the terminal to use and connect the device.
•When using just one surround back speaker, connect it to the left channel (L) terminal.
•Use the volume control on the subwoofer to control subwoofer volume.
•If the subwoofer volume sounds low, use the volume control provided on the subwoofer to adjust the
volume.
NOTE
When external power amplifier have been connected to PRE OUT terminals, do not connect the speakers
to the speaker terminals.
L
L
L
L
L
L
R R R
RR R
SUB-
WOOFER
2
SUB-
WOOFER
1
CENTER SURROUND
BACK
RL
SURROUND
RL
FRONT
RL
AUDIOAUDIO
Power amplifierSubwoofer
Basic version
Advanced version
