71
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
7.1CH PREOUT PWB
(
CUP11823-6
)
7.1PRE C170 ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
7.1PRE C171 ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
7.1PRE C172 ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
7.1PRE C173 ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
7.1PRE C174 ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
7.1PRE C175 ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
7.1PRE C176 ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
7.1PRE C177 ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
7.1PRE CN22 ns
p
ns
p
CONN. WAFER KJP15GA19ZM
7.1PRE JK15 90M-YT004040R 90M-YT004040R TERMINAL RCA-401DA-28 CJJ4P051Z
7.1PRE JK16 90M-YT004050R 90M-YT004050R TERMINAL RCA-401DA-16 CJJ4P052Z
AMP PWB
(
CUP11824Z
)
AMP BN23 ns
p
ns
p
CORD WIRE ASSY CWZSR7400BN23
AMP BN24 ns
p
ns
p
CORD WIRE ASSY CWZSR7400BN24
AMP BN25 ns
p
ns
p
CORD WIRE ASSY CWB1B905180EN
AMP BN70 ns
p
ns
p
CORD WIRE ASSY CWZSR5500BN70
AMP C401 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
AMP C402 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
AMP C403 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
AMP C404 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
AMP C405 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100DC
AMP C406 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100DC
AMP C407 90M-OF100350R 90M-OF100350R FILM CAP. 2200PF 50V J HCQI1H222JZT
AMP C408 90M-OF100350R 90M-OF100350R FILM CAP. 2200PF 50V J HCQI1H222JZT
AMP C409 ns
p
00MOA22605020 ELECT CAP. 22UF 50V HCEA1HH220T
AMP C410 ns
p
00MOA22605020 ELECT CAP. 22UF 50V HCEA1HH220T
AMP C411 ns
p
00MOA10706320 ELECT CAP. 100UF 63V HCEA1JH101E
AMP C412 ns
p
00MOA10706320 ELECT CAP. 100UF 63V HCEA1JH101E
AMP C413 ns
p
00MOA10706320 ELECT CAP. 100UF 63V HCEA1JH101E
AMP C414 ns
p
00MOA10706320 ELECT CAP. 100UF 63V HCEA1JH101E
AMP C419 ns
p
00MOA10705020 ELECT CAP. 100UF 50V HCEA1HH101T
AMP C420 ns
p
00MOA10705020 ELECT CAP. 100UF 50V HCEA1HH101T
AMP C421 ns
p
00MOA10701620 ELECT CAP. 100UF 16V HCEA1CH101T
AMP C422 ns
p
00MOA10701620 ELECT CAP. 100UF 16V HCEA1CH101T
AMP C501 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
AMP C502 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
AMP C503 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
AMP C504 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
AMP C505 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100DC
AMP C506 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100DC
AMP C507 90M-OF100350R 90M-OF100350R FILM CAP. 2200PF 50V J HCQI1H222JZT
AMP C508 90M-OF100350R 90M-OF100350R FILM CAP. 2200PF 50V J HCQI1H222JZT
AMP C509 ns
p
00MOA22605020 ELECT CAP. 22UF 50V HCEA1HH220T
AMP C510 ns
p
00MOA22605020 ELECT CAP. 22UF 50V HCEA1HH220T
AMP C511 ns
p
00MOA10706320 ELECT CAP. 100UF 63V HCEA1JH101E
AMP C512 ns
p
00MOA10706320 ELECT CAP. 100UF 63V HCEA1JH101E
AMP C513 ns
p
00MOA10706320 ELECT CAP. 100UF 63V HCEA1JH101E
AMP C514 ns
p
00MOA10706320 ELECT CAP. 100UF 63V HCEA1JH101E
AMP C519 ns
p
00MOA10705020 ELECT CAP. 100UF 50V HCEA1HH101T
AMP C520 ns
p
00MOA10705020 ELECT CAP. 100UF 50V HCEA1HH101T
AMP C521 ns
p
00MOA10701620 ELECT CAP. 100UF 16V HCEA1CH101T
AMP C522 ns
p
00MOA10701620 ELECT CAP. 100UF 16V HCEA1CH101T
AMP C601 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
AMP C602 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
AMP C603 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
AMP C604 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
AMP C605 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100DC
AMP C606 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100DC
AMP C607 90M-OF100350R 90M-OF100350R FILM CAP. 2200PF 50V J HCQI1H222JZT
AMP C608 90M-OF100350R 90M-OF100350R FILM CAP. 2200PF 50V J HCQI1H222JZT
AMP C609 ns
p
00MOA22605020 ELECT CAP. 22UF 50V HCEA1HH220T
AMP C610 ns
p
00MOA22605020 ELECT CAP. 22UF 50V HCEA1HH220T
AMP C611 ns
p
00MOA10706320 ELECT CAP. 100UF 63V HCEA1JH101E
AMP C612 ns
p
00MOA10706320 ELECT CAP. 100UF 63V HCEA1JH101E
AMP C613 ns
p
00MOA10706320 ELECT CAP. 100UF 63V HCEA1JH101E
AMP C614 ns
p
00MOA10706320 ELECT CAP. 100UF 63V HCEA1JH101E
POS. NO.
