Marantz SR5600 - Page 63

81
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
COMPO. C955 ns
p
00MOA47602520 ELECT CAP. 47UF 25V HCEA1EH470T
COMPO. C956 ns
p
00MOA47602520 ELECT CAP. 47UF 25V HCEA1EH470T
COMPO. C957 ns
p
00MOA47602520 ELECT CAP. 47UF 25V HCEA1EH470T
COMPO. CN42 ns
p
ns
p
CONN. GF102-07S-TS KJP07GA117ZG
COMPO. IC91 00MHC10229090 00MHC10229090 IC NJM2584D VIDEO HVINJM2584D
COMPO. IC94 90M-HC108960R 90M-HC108960R IC NJM2586
L
HVINJM2586
L
COMPO. J901 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. J902 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. J903 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. J904 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. J905 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. J906 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. J908 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. J909 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. J910 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. J911 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. J912 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. J913 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. J914 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. J915 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. J916 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. J917 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. J918 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. J919 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. J920 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. J921 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. J922 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. J928 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. J931 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. J932 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
COMPO. JK91 90M-YT003210R 90M-YT003210R TERMINAL CINCH 3P G/B/R SILVER CJJ4S030Z
COMPO. JK92 90M-YT003210R 90M-YT003210R TERMINAL CINCH 3P G/B/R SILVER CJJ4S030Z
COMPO. JK95 90M-YT003210R 90M-YT003210R TERMINAL CINCH 3P G/B/R SILVER CJJ4S030Z
COMPO. Q901 00MHT30001000 00MHT30001000 TRS. KTC3199Y HVTKTC3199Y
T
COMPO. Q902 00MHT600111B0 00MHT600111B0 TRS. KTA1267
Y
HVTKTA1267Y
T
COMPO. R901 ns
p
ns
p
RES. 75 OHM 1/5W J CRD20TJ750
T
COMPO. R902 ns
p
ns
p
RES. 75 OHM 1/5W J CRD20TJ750
T
COMPO. R903 ns
p
ns
p
RES. 75 OHM 1/5W J CRD20TJ750
T
COMPO. R904 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105
T
COMPO. R905 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105
T
COMPO. R906 ns
p
ns
p
RES. 75 OHM 1/5W J CRD20TJ750
T
COMPO. R907 ns
p
ns
p
RES. 75 OHM 1/5W J CRD20TJ750
T
COMPO. R908 ns
p
ns
p
RES. 75 OHM 1/5W J CRD20TJ750
T
COMPO. R931 ns
p
ns
p
RES. 75 OHM 1/5W J CRD20TJ750
T
COMPO. R932 ns
p
ns
p
RES. 75 OHM 1/5W J CRD20TJ750
T
COMPO. R933 ns
p
ns
p
RES. 75 OHM 1/5W J CRD20TJ750
T
COMPO. R934 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105
T
COMPO. R935 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105
T
COMPO. R936 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105
T
COMPO. R941 ns
p
ns
p
RES. 12K OHM 1/5W J CRD20TJ123
T
COMPO. R942 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
COMPO. R943 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471
T
COMPO. R945 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471
T
COMPO. R946 ns
p
ns
p
RES. 470 OHM 1/5W J CRD20TJ471
T
COMPO. R947 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
COMPO. R951 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
DSP PWB
(
CUP11826Z
)
DSP BC11 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
DSP BC12 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
DSP BN33 ns
p
ns
p
CONN. MOLEX53014-0710 KJP07GA19ZM
DSP C101 ns
p
00MOA47601640 ELECT CAP. 47UF 16V HCEA1CH470T
DSP C102 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC HCUS1H103KC
DSP C103 ns
p
00MOA47601640 ELECT CAP. 47UF 16V HCEA1CH470T
DSP C104 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC HCUS1H103KC
DSP C105 ns
p
00MOA22605020 ELECT CAP. 22UF 25V HCEA1EH220T
DSP C106 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V ZF HCUS1E104ZF
DSP C107 ns
p
00MDD95101300 CER. CAP. 100PF 50V J
A
HCUS1H101JA
