Marantz SR5600 - Page 67

85
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
DSP CC37 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V ZF HCUS1E104ZF
DSP CC38 ns
p
00MOA10701620 ELECT CAP. 100UF 16V HCEA1CH101T
DSP CC39 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V ZF HCUS1E104ZF
DSP CC40 ns
p
00MOA10701620 ELECT CAP. 100UF 16V HCEA1CH101T
DSP CC41 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V ZF HCUS1E104ZF
DSP CC42 ns
p
00MOA10701620 ELECT CAP. 100UF 16V HCEA1CH101T
DSP CC43 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V ZF HCUS1E104ZF
DSP CC44 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V ZF HCUS1E104ZF
DSP CN16 ns
p
ns
p
CONN. GF102-16S-TS KJP16GA117ZG
DSP CN26 ns
p
ns
p
CONN. C.CABLE KJP19GA117ZG
DSP CN28 ns
p
ns
p
CONN. GF120-17S-TS KJP17GA115ZG
DSP CN30 ns
p
ns
p
CONN. MOLEX53014-0910 KJP09GA19ZM
DSP CN34
/
A1B ns
p
ns
p
CONN. GF120-17S-TS KJP17GA115ZG
DSP CN34
/
A1S ns
p
ns
p
CONN. GF120-17S-TS KJP17GA115ZG
DSP CN34
/
N1B ns
p
ns
p
CONN. GF120-17S-TS KJP17GA115ZG
DSP CN34
/
N1G ns
p
ns
p
CONN. GF120-17S-TS KJP17GA115ZG
DSP CN34
/
N1S ns
p
ns
p
CONN. GF120-17S-TS KJP17GA115ZG
DSP CN34
/
U1B ns
p
ns
p
CONN. GF120-15S-TS KJP15GA115ZG
DSP CN36 ns
p
ns
p
CONN. C.CABLE KJP11GA117ZG
DSP CN38 ns
p
ns
p
CONN. GF102-13S-TS KJP13GA117ZG
DSP CN40 ns
p
ns
p
CONN. MOLEX53014-0610 KJP06GA19ZM
DSP DC10
/
A1B ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
DSP DC10
/
A1S ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
DSP DC10
/
N1B ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
DSP DC10
/
N1G ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
DSP DC10
/
N1S ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
DSP DC11 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
DSP DC12
/
U1B ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
DSP DC16 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
DSP ET01 ns
p
ns
p
TERMINAL PLATE, EARTH CNE75
DSP ET02 ns
p
ns
p
TERMINAL PLATE, EARTH CNE75
DSP IC11 90M-HC700550R 90M-HC700550R IC TC74HCU04AFNG HVI74HCU04AFNG
DSP IC12 90M-HC700550R 90M-HC700550R IC TC74HCU04AFNG HVI74HCU04AFNG
DSP IC13 00MHC10418030 00MHC10418030 IC LC89057W-VF4-E HVILC89057WVF4E
DSP IC14 00MHC10172090 00MHC10172090 IC NJM2115MD OP AMP HVINJM2115MDTE1
DSP IC15 00MHC10172090 00MHC10172090 IC NJM2115MD OP AMP HVINJM2115MDTE1
DSP IC16 00MHC10012880 00MHC10012880 IC CS4382-KQ D/A CONVERTER HVICS4382-KQ
DSP IC17 90M-HC108910R 90M-HC108910R IC 74VHC08 HVI74VHC08TTR
DSP IC18 90M-HC108430R 90M-HC108430R IC TC74HC7007AFE
L
HVITC74HCT7007F
DSP IC19 00MHC10014880 00MHC10014880 IC CS49400-CQ DECODER HVICS49400-CQ
DSP IC20 90M-HS08BWX0R 90M-HS08BWX0R U-PRO MX29LV400TTC-70, SR550
0
HVIMX29LV400TTC
DSP IC21 90M-HC108910R 90M-HC108910R IC 74VHC08 HVI74VHC08TTR
DSP IC22 90M-HC108930R 90M-HC108930R IC 74LCX32 HVI74LCX32TTR
DSP IC23 90M-HC108970R 90M-HC108970R IC HY57V161610ET-7 HVI57V161610ET7
DSP IC24 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
DSP IC25 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
DSP IC26 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
DSP IC27 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
DSP IC28 90M-HS43BWH0R 90M-HS43BWH0R U-PRO HD64F2398F20, SR560
0
HVIHD64F2398F20
DSP IC29 00MHC10099540 00MHC10099540 IC S-80145ALMC HVIS-80145ALMC
DSP IC30 90M-HC108390R 90M-HC108390R IC AT24C08N10SC2.7 HVIAT24C08N10SC
DSP IC31 00MHC36J3305
Y
00MHC36J3305
Y
IC TA48033FTE16 HVITA48033FTE16
DSP IC32 00MHC36J25050 00MHC36J25050 IC TA48025FTE16 HVITA48025FTE16
DSP IC33 90M-HC108440R 90M-HC108440R IC ST202EBW RS-232C HVIST202EBW
DSP IC34 90M-HW100710R 90M-HW100710R PHOTO UNIT PC-17L1CB HVIPC17L1CB
DSP IC35 00MHC10015880 00MHC10015880 IC CS5361-KS A/D CONVERTER HVICS5361-KS
DSP JK11 90M-YT004060R 90M-YT004060R TERMINAL YKC22-0735N HJS9U002Z
DSP JK12 90M-YT004060R 90M-YT004060R TERMINAL YKC22-0735N HJS9U002Z
DSP JK14 90M-YT004070R 90M-YT004070R TERMINAL YKC22-0734N HJS9U001Z
DSP JK15 90M-YT003300R 90M-YT003300R TERMINAL D-SUB 9P MALE KJP09TA87WM
DSP JK16 90M-YT003120R 90M-YT003120R TERMINAL CINCH 2P
(
GOLD
)
CJJ4N036Z
DSP JK20 90M-YT003650R 90M-YT003650R TERMINAL CINCH 2P GREEN SILVER CJJ4N071Z
DSP L101 00MFC90020120 00MFC90020120 FERRITE CORE BK 1608 HM 102
T
HLZ92003Z
DSP LC72 ns
p
00MNN05000610 CHIP RES. 0 OHM 1/10W J HRJ10DJ0R0
T
DSP LC79 ns
p
00MNN05000610 CHIP RES. 0 OHM 1/10W J HRJ10DJ0R0
T
DSP LC80 ns
p
00MNN05000610 CHIP RES. 0 OHM 1/10W J HRJ10DJ0R0
T
DSP LC81 ns
p
00MNN05000610 CHIP RES. 0 OHM 1/10W J HRJ10DJ0R0
T
