Marantz SR5600 - Page 79

97
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
INPUT D207 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
INPUT D208 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
INPUT D209 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
INPUT D210 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
INPUT D211 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
INPUT D212 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
INPUT D213 ns
p
90M-HD201730R DIODE 1N4003 KVD1N4003S
T
INPUT D214 ns
p
90M-HD201730R DIODE 1N4003 KVD1N4003S
T
INPUT D216 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
INPUT ET21 ns
p
ns
p
TERMINAL PLATE, EARTH CNE75
INPUT IC21 00MHC10470050 00MHC10470050 IC TC9164AN FUNCTION HVITC9164AN
INPUT IC22 00MHC10468050 00MHC10468050 IC TC9273N FUNCTION HVITC9273N
INPUT IC23 00MHC10469050 00MHC10469050 IC TC9162AN FUNCTION HVITC9162AN
INPUT IC24 00MHC10467050 00MHC10467050 IC TC9499N VOLUME HVITC9499N
INPUT IC25 00MHC10467050 00MHC10467050 IC TC9499N VOLUME HVITC9499N
INPUT IC26 90M-HC300550R 90M-HC300550R IC KA7806 REGULATOR HVIMC7806
INPUT IC27 90M-HC300540R 90M-HC300540R IC KA7906 REGULATOR HVIKA7906
INPUT IC28 00MHC10053090 00MHC10053090 IC NJM2068DD HVINJM2068DD
INPUT IC29 00MHC10053090 00MHC10053090 IC NJM2068DD HVINJM2068DD
INPUT IC30 00MHC10053090 00MHC10053090 IC NJM2068DD HVINJM2068DD
INPUT IC31 00MHC10053090 00MHC10053090 IC NJM2068DD HVINJM2068DD
INPUT IC32 00MHC10053090 00MHC10053090 IC NJM2068DD HVINJM2068DD
INPUT IC33 00MHC10053090 00MHC10053090 IC NJM2068DD HVINJM2068DD
INPUT IC34 00MHC10053090 00MHC10053090 IC NJM2068DD HVINJM2068DD
INPUT IC35 00MHC10053090 00MHC10053090 IC NJM2068DD HVINJM2068DD
INPUT IC36 00MHC10053090 00MHC10053090 IC NJM2068DD HVINJM2068DD
INPUT IC37 00MHC10053090 00MHC10053090 IC NJM2068DD HVINJM2068DD
INPUT IC38 00MHC10468050 00MHC10468050 IC TC9273N FUNCTION HVITC9273N
INPUT IC40 00MHC10053090 00MHC10053090 IC NJM2068DD HVINJM2068DD
INPUT IC41 00MHC10053090 00MHC10053090 IC NJM2068DD HVINJM2068DD
INPUT J001 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J002 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J003 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J004 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J005 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J006 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J007 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J008 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J010 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J011 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J013 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J014 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J015 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J016 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J017 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J018 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J019 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J020 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J021 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J022 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J023 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J024 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J025 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J026 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J027 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J028 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J029 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J030 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J031 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J032 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J033 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J034 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J035 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J036 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J037 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J038 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
INPUT J039 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
