Marantz SR5600 - Page 87

105
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
INPUT R407 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R408 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R409 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R410 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472
T
INPUT R411 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333
T
INPUT R413 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R414 ns
p
ns
p
RES. 220 OHM 1/5W J CRD20TJ221
T
INPUT R415 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105
T
INPUT R416 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R417 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R418 ns
p
ns
p
RES. 220 OHM 1/5W J CRD20TJ221
T
INPUT R419 ns
p
ns
p
RES. 33 OHM 1/6W J CRD20TJ330
T
INPUT R420 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R421 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472
T
INPUT R423 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472
T
INPUT R424 ns
p
ns
p
RES. 220 OHM 1/5W J CRD20TJ221
T
INPUT R425 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R426 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R427 ns
p
ns
p
RES. 220 OHM 1/5W J CRD20TJ221
T
INPUT R428 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472
T
INPUT R429 ns
p
ns
p
RES. 4.7K OHM 1/5W J CRD20TJ472
T
INPUT R431 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R432 ns
p
ns
p
RES. 1M OHM 1/5W J CRD20TJ105
T
INPUT R433 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R434 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R435 ns
p
ns
p
RES. 220 OHM 1/5W J CRD20TJ221
T
INPUT R436 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R437 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
INPUT R438 ns
p
ns
p
RES. 220 OHM 1/5W J CRD20TJ221
T
INPUT R439 ns
p
ns
p
RES. 33 OHM 1/6W J CRD20TJ330
T
INPUT R440 ns
p
ns
p
RES. 33 OHM 1/6W J CRD20TJ330
T
INPUT R441 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
INPUT R442 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R444 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R445 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R446 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
INPUT R447 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101
T
INPUT R448 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
INPUT R449 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473
T
PUSH S/W PWB
(
CUP11823-5
)
P S/W C877
/
A1B nsp 90M-DK100800R CER. CAP. ! DKS471ME KCKDKS471ME
P S/W C877
/
A1S nsp 90M-DK100800R CER. CAP. ! DKS471ME KCKDKS471ME
P S/W C877
/
N1B 90M-DK100800R 90M-DK100800R CER. CAP. ! DKS471ME KCKDKS471ME
P S/W C877
/
N1G 90M-DK100800R 90M-DK100800R CER. CAP. ! DKS471ME KCKDKS471ME
P S/W C877
/
N1S 90M-DK100800R 90M-DK100800R CER. CAP. ! DKS471ME KCKDKS471ME
P S/W CN88
/
A1B ns
p
90M-YP100250R CONN. MOLEX35328-02 KJP02GA89ZM
P S/W CN88
/
A1S ns
p
90M-YP100250R CONN. MOLEX35328-02 KJP02GA89ZM
P S/W CN88
/
N1B 90M-YP100250R 90M-YP100250R CONN. MOLEX35328-02 KJP02GA89ZM
P S/W CN88
/
N1G 90M-YP100250R 90M-YP100250R CONN. MOLEX35328-02 KJP02GA89ZM
P S/W CN88
/
N1S 90M-YP100250R 90M-YP100250R CONN. MOLEX35328-02 KJP02GA89ZM
P S/W SW97
/
A1B nsp 90M-SP001250R SW ! JPP1197CSA64 KSH1A001ZV
P S/W SW97
/
A1S nsp 90M-SP001250R SW ! JPP1197CSA64 KSH1A001ZV
P S/W SW97
/
N1B 90M-SP001250R 90M-SP001250R SW ! JPP1197CSA64 KSH1A001ZV
P S/W SW97
/
N1G 90M-SP001250R 90M-SP001250R SW ! JPP1197CSA64 KSH1A001ZV
P S/W SW97
/
N1S 90M-SP001250R 90M-SP001250R SW ! JPP1197CSA64 KSH1A001ZV
POWER PWB
(
CUP11827-1
)
POWER ns
p
ns
p
HEATSINK SUB HEATSINK CMY1A207
POWER BN65 ns
p
ns
p
CORD WIRE ASSY CWB3F006100UZ
POWER C600 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
POWER C601 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
POWER C602 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
POWER C603 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
POWER C604 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
POWER C605 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
POWER C606 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
POWER C611 ns
p
ns
p
CER. CAP. 1000PF 50V KB CCKT1H102KB
POWER C612 ns
p
ns
p
CER. CAP. 1000PF 50V KB CCKT1H102KB
