Marantz SR5600 - Page 91

109
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
POWER R613 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R614 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R615 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R616 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R617 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R618 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R619 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R620 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R621 ns
p
ns
p
RES. 10 OHM 1W J KRG1SANJ100RT
POWER R622 ns
p
ns
p
RES. 10 OHM 1W J KRG1SANJ100RT
POWER R623 ns
p
ns
p
RES. 10 OHM 1W J KRG1SANJ100RT
POWER R624 ns
p
ns
p
RES. 10 OHM 1W J KRG1SANJ100RT
POWER R625 ns
p
ns
p
RES. 10 OHM 1W J KRG1SANJ100RT
POWER R626 ns
p
ns
p
RES. 10 OHM 1W J KRG1SANJ100RT
POWER R627 ns
p
ns
p
RES. 330 OHM 1
W
CRG1ANJ331H
POWER R628 ns
p
ns
p
RES. 330 OHM 1
W
CRG1ANJ331H
POWER R631 ns
p
ns
p
RES. 150 OHM 1/4W J CRD25TJ151
T
POWER R632 ns
p
ns
p
RES. 150 OHM 1/4W J CRD25TJ151
T
POWER R633 ns
p
ns
p
RES. 15K OHM 1/5W J CRD20TJ153
T
POWER R634 ns
p
ns
p
RES. 15K OHM 1/5W J CRD20TJ153
T
POWER R635 ns
p
ns
p
RES. 15K OHM 1/5W J CRD20TJ153
T
POWER R636 ns
p
ns
p
RES. 15K OHM 1/5W J CRD20TJ153
T
POWER R637 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R638 ns
p
ns
p
RES. 33K OHM 1/5W J CRD20TJ333
T
POWER R639 ns
p
ns
p
RES. 100K OHM 1/5W J CRD20TJ104
T
POWER R640 ns
p
ns
p
RES. 1 OHM 1W CRG1ANJ1R0H
POWER R641 ns
p
ns
p
RES. 1 OHM 1W CRG1ANJ1R0H
POWER R642 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R643 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R644 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223
T
POWER R645 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223
T
POWER R646 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103
T
POWER R647 ns
p
ns
p
RES. 1 OHM 1/4W J CRD25TJ1R0T
POWER R648 ns
p
ns
p
RES. 2.2K OHM 1W J KRG1SANJ222RT
POWER R649 ns
p
ns
p
RES. 1.5K OHM 1W J KRG1SANJ152RT
POWER R650 ns
p
ns
p
RES. 100 OHM 1/4W J CRD25TJ101
T
POWER R651 ns
p
ns
p
RES. 100 OHM 1/4W J CRD25TJ101
T
POWER R652 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
POWER R653 90M-NH000150R 90M-NH000150R FUSE RES. ! 0.15 OHM 1W J KRQ1AJR15H
POWER RY61 00MLY2024049
0
00MLY2024049
0
RELAY 5GPA-28 DC24 HSL3B013ZE
POWER RY62 00MLY2024049
0
00MLY2024049
0
RELAY 5GPA-28 DC24 HSL3B013ZE
POWER RY63 00MLY2024049
0
00MLY2024049
0
RELAY 5GPA-28 DC24 HSL3B013ZE
POWER RY64 00MLY2024049
0
00MLY2024049
0
RELAY 5GPA-28 DC24 HSL3B013ZE
POWER RY65 00MLY2024051
0
00MLY2024051
0
RELAY OSA-SS-224DM3 HSL4B017ZU
POWER RY66 00MLY2024052
0
00MLY2024052
0
RELAY ! PCLH-203D1SP HSL4B018ZU
STANDBY PWB
(
CUP11823-3
)
ST-BY BK81 ns
p
ns
p
BRACKET BRACKET PWB CMD1A387
ST-BY BK82 ns
p
ns
p
BRACKET BRACKET PWB CMD1A387
ST-BY C881 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
ST-BY C882 ns
p
00MOA47505020 ELECT CAP. 4.7UF 50V HCEA1HH4R7T
ST-BY C883 ns
p
00MOA10701620 ELECT CAP. 100UF 16V HCEA1CH101T
ST-BY C884 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
ST-BY C885 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
ST-BY C886 ns
p
00MOA33802520 ELECT CAP. 3300UF 25
V
HCEA1EH332E
ST-BY C887 ns
p
ns
p
CER. CAP. 1000PF 50V B HCBS1H102KBT
ST-BY C888 90M-DK100810R 90M-DK100810R CER. CAP. ! WKH103MF HCKWKH103MF
ST-BY CN90 ns
p
ns
p
CONN. CONNECTOR KJP05GB99ZM
ST-BY CN91
/
A1B ns
p
90M-YP100250R CONN. MOLEX35328-02 KJP02GA89ZM
ST-BY CN91
/
A1S ns
p
90M-YP100250R CONN. MOLEX35328-02 KJP02GA89ZM
ST-BY CN91
/
N1B 90M-YP100250R 90M-YP100250R CONN. MOLEX35328-02 KJP02GA89ZM
ST-BY CN91
/
N1G 90M-YP100250R 90M-YP100250R CONN. MOLEX35328-02 KJP02GA89ZM
ST-BY CN91
/
N1S 90M-YP100250R 90M-YP100250R CONN. MOLEX35328-02 KJP02GA89ZM
ST-BY CN92 90M-YP100250R 90M-YP100250R CONN. MOLEX35328-02 KJP02GA89ZM
ST-BY CN93 90M-YP100250R 90M-YP100250R CONN. MOLEX35328-02 KJP02GA89ZM
ST-BY D802 ns
p
00MHD20015210 DIODE 1SS133T-77 HVD1SS133M
T
ST-BY D803 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
ST-BY D804 ns
p
90M-HD201750R DIODE 1N4003 KVD1N4003SRT
