113
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
V CONV. R138 ns
p
00MNN05102610 CHIP RES. 1K OHM 1/10W J HRJ10DJ102
T
V CONV. R139 ns
p
00MNN05102610 CHIP RES. 1K OHM 1/10W J HRJ10DJ102
T
V CONV. R140 ns
p
00MNN05471610 CHIP RES. 470 OHM 1/10W J HRJ10DJ471
T
V CONV. R141 ns
p
00MNN05471610 CHIP RES. 470 OHM 1/10W J HRJ10DJ471
T
V CONV. R142 ns
p
00MNN05471610 CHIP RES. 470 OHM 1/10W J HRJ10DJ471
T
V CONV. R143 ns
p
00MNN05103610 CHIP RES. 10K OHM 1/10W J HRJ10DJ103
T
V CONV. R144 ns
p
00MNN05333610 CHIP RES. 33K OHM 1/10W J HRJ10DJ333
T
V CONV. R145 ns
p
00MNN05332610 CHIP RES. 3.3K OHM 1/10W J HRJ10DJ332
T
V CONV. R146 ns
p
00MNN05331610 CHIP RES. 330 OHM 1/10W J HRJ10DJ331
T
V CONV. R147 ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J HRJ10DJ101
T
V CONV. R148 ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J HRJ10DJ101
T
V CONV. R149 ns
p
00MNN05101610 CHIP RES. 100 OHM 1/10W J HRJ10DJ101
T
V CONV. R200 ns
p
00MNN05472610 CHIP RES. 4.7K OHM 1/10W J HRJ10DJ472
T
V CONV. R201 ns
p
00MNN05472610 CHIP RES. 4.7K OHM 1/10W J HRJ10DJ472
T
V CONV. VR11 90M-RA001080R 90M-RA001080R TRIM. RES. RH0638C-471 HVN1RA471B01
T
V CONV. VR12 90M-RA001080R 90M-RA001080R TRIM. RES. RH0638C-471 HVN1RA471B01
T
V CONV. X100
/
A1B ns
p
90M-JX001160R X'TAL 4.433MHZ HOX04433E120TF
V CONV. X100
/
A1S ns
p
90M-JX001160R X'TAL 4.433MHZ HOX04433E120TF
V CONV. X100
/
N1B 90M-JX001160R 90M-JX001160R X'TAL 4.433MHZ HOX04433E120TF
V CONV. X100
/
N1G 90M-JX001160R 90M-JX001160R X'TAL 4.433MHZ HOX04433E120TF
V CONV. X100
/
N1S 90M-JX001160R 90M-JX001160R X'TAL 4.433MHZ HOX04433E120TF
V CONV. X101 90M-JX001220R 90M-JX001220R X'TAL 3.57MHZ H2OX03579D140TF
V CONV. X102 90M-FQ000580R 90M-FQ000580R CER. VIB. CERAMINC, RESONATOR HVFCSBLA503KECZ
VIDEO PWB
(
CUP11827Z
)
VIDEO BN21 ns
p
ns
p
CORD WIRE ASSY CWB1C906270EN
VIDEO C702 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
VIDEO C704 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
VIDEO C706 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
VIDEO C707 ns
p
ns
p
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C708 ns
p
00MOA47701020 ELECT CAP. 470UF 10V HCEA1AH471T
VIDEO C710 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
VIDEO C711 ns
p
ns
p
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C712 ns
p
00MOA47701020 ELECT CAP. 470UF 10V HCEA1AH471T
VIDEO C713 ns
p
ns
p
CER. CAP. 68PF 50V JC CCCT1H680JC
VIDEO C714 ns
p
00MOA47701020 ELECT CAP. 470UF 10V HCEA1AH471T
VIDEO C715 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
VIDEO C716 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
VIDEO C717 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
VIDEO C719 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
VIDEO C720 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
VIDEO C722 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
VIDEO C723 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
VIDEO C725 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
VIDEO C726 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
VIDEO C727 ns
p
ns
p
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C728 ns
p
00MOA47701020 ELECT CAP. 470UF 10V HCEA1AH471T
VIDEO C729 ns
p
ns
p
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C730 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
VIDEO C732 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
VIDEO C733 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
VIDEO C734 ns
p
ns
p
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C735 ns
p
00MOA47701020 ELECT CAP. 470UF 10V HCEA1AH471T
VIDEO C736 ns
p
ns
p
CER. CAP. 47PF 50V JC CCCT1H470JC
VIDEO C737 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
VIDEO C738 ns
p
ns
p
CER. CAP. 68PF 50V JC CCCT1H680JC
VIDEO C739 ns
p
00MOA47701020 ELECT CAP. 470UF 10V HCEA1AH471T
VIDEO C740 ns
p
ns
p
CER. CAP. 68PF 50V JC CCCT1H680JC
VIDEO C741 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
VIDEO C742 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
VIDEO C743 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
VIDEO C744 ns
p
00MOA22505020 ELECT CAP. 2.2UF 50V HCEA1HH2R2T
VIDEO C745 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
VIDEO C746 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
VIDEO C747 ns
p
00MOA10605020 ELECT CAP. 10UF 50V HCEA1HH100T
VIDEO C748 ns
p
ns
p
CER. CAP. 0.01UF 50V ZF CCKT1H103ZF
VIDEO C749 ns
p
00MOA10701620 ELECT CAP. 100UF 16V HCEA1CH101T
VIDEO C751 ns
p
00MOA47505020 ELECT CAP. 4.7UF 50V HCEA1HH4R7T
