Marantz SR6009/U1B - Page 110

+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
SR6009
LEVEL DIAGRAM
CENTER ch
-2-0.5dB
200mVrms
+30dB
SP OUT
4.48Vrms/8Ω
+29dB
-2+6=+4dB
MAX. SIGNAL LEVEL
DOLBY LIMIT LEVEL (ALLch-3dBFS)
-2.6dB
-20dBFS(DIG.IN:PCM or DD Config1)
＋
＋
SPEAKER
DSP
R2A15218FP
GAIN
ADJ.
PCM1690
D/A
－
－
＋
PLD
-2.6dB
2.83Vrms=0dBFS
-10dBFS
-20dBFS
-30dBFS
-40dBFS
PCM1690Differential Out
-2.6dB
R2A15218FP MAX. OUTPUT 3.8Vrms
MUTE
PRE OUT
PRE OUT
159mVrms
-2+6dB=4dB
-26.5dBFS(A/D IN)
-26.5dBFS(DIG.IN DD Config2)
HDAM
(N Only)
110
