Marantz SR6009/U1B - Radiator Assy

2. RADIATOR ASSY
Proceeding : TOP COVER → FRONT PANEL ASSY → RADIATOR ASSY
(1) Remove the screws.
(2)
Cut
the wire clamp. Remove the screws.
(3) Remove the connector wire.
View from the bottom
CUT
CN703
CN461
CN704
CN702
CN701
CUT
14
