Marantz SR6009/U1B - WIRING DIAGRAM for CX920

WIRING DIAGRAM FOR CX920
s
H/P PCB
FRONT VFD PCB
WIRE/5P/2.0mm/600mm
BN63A
ENCODER PCB
FUNCTION
BN63B
VOLUME ENCODER PCB
CN605
USB JACK
BN605
MIC
FL601
CUP12624Z
AUX
YMAW025-07R
CUP12624-2
(CWB8A005600HC)
UL2725#24/#28,1P+2C
CJP05GB280ZK
CN69A
FPC 1.0-11S-40PW
FFC WAFER/40P
FRONT HDMI PCB
FFC WAFER/23P
CJP23GA193ZY
CJP05GA279ZK
SMPS PCB
INLET
7808
7908
7805
7905
7805
VIDEO PCB
INPUT PCB
FRONT CNT. PCB
SIDE CNT.PCB
TUNER PACK
AMP PCB
WAFER/13pin-2mm
WIRE/7pin-2.0mm/250mm
WAFER/6pin-2.5mm
WAFER/7pin-2.5mm
CN701
DIGITAL PCB
MAIN TRANS
WAFER/7pin-3.96mm/DIP
WAFER/3pin-2.5mm
WAFER, 2P, 7.92mm
WAFER/2.5mm-05P
(DIGITAL POWER)
WIRING DIAGRAM
CN902
BN903
WIRE/5pin-2.5mm
WIRE/7pin-2.5mm/270mm
FL PWR
(SEC 5,6)
CN461
BN710
WAFER/4pin-2.5mm
CN703
CN704
CUP12625Z
BN703
WIRE/6pin-2.5mm/400mm
BN704
CN971
(S1)
WIRE/5pin-3.96mm/220mm
(AMP PWR)
WIRE/03P/2.5mm/300mm
(S3/S4)
(S2)
CN941
WAFER/5pin-2.5mm
CN940
WIRE/4pin-2.5mm/220mm
WIRE/02pin-3.96mm/130mm
(PRI.)
FUSE PCB
CUP12641Z
CUP12521Z-3
CN903
CUP12638Z
WAFER/7p/2mm
(THERMAL DET)
CN704
CUP12534Z
WIRE/13pin-2mm/150mm
CN801
CUP12634Z
CUP12630Z_A_1
CUP12630Z_A_2
SPK, REG. PCB
CUP12627Z
UL1007#26
400mm,UL1569#22,105
(CWB7D0054003D)
CN932
WAFER/9pin-2.0mm
7812
CN69B
CN431
WAFER, FFC, SMD(23P-1mm)
(FRONT HDMI)
WAFER, FFC, SMD(40P-1mm, STRAIGHT)
(SR6009) CY920 ONLY
BN932
UL1007#26
CN706S
WIRE/3pin-2.0mm
WIRE/3in-2.0mm/150mm
BN706
WIRE/7pin-2.5mm/180mm
WIRE/4P-2.5mm/220mm
BN701
WIRE/5pin-2.5mm/220mm
BN702
WAFER/5pin-2.5mm
CN702
WIRE 9pin-2.0mm, 220mm
CN901
WAFER, 2P, 3.96mm
UL1569#24,105
UL1569#20,105
UL1569#20,105
UL1569#20,105
UL1569#20,105
UL1007#26
CON1
CON2
WiFi Antenna
Wi
Fi Antenna
BRIDGE DIODE
CUP12640Z
REMOCON SENSE
CWB1C005100CC
WIRE/5P/2mm/100mm
CN541
BN321
WAFER/5P/2.0mm
CUP12666-1
CY920
WiFi/BT Antenna
WiFi/BT Antenna
118
