Marantz SR6009/U1B - Level Diagram

LEVEL DIAGRAM
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
LINE IN
-10dBFS
0dBFS=1.06Vrms
-20dBFS
-30dBFS
-40dBFS
A/D IN
50mVrms
(-26.5dBFS)
PCM9211
H/P OUT
294mVrms/33
SR6009
LEVEL DIAGRAM
FRONT ch
-12dB
-2-0.5dB
-23.7dB
200mVrms
+30dB
SP OUT
4.48Vrms/8Ω
+29dB
-2+6=+4dB
MAX. SIGNAL LEVEL
DOLBY LIMIT LEVEL (ALLch-3dBFS)
GAIN setting of MASTER VOL 00dB
･SW:YES (DIGITAL) -2dB -0.5dB= -2.5dB
･SW:YES (ANALOG) -2dB+ 6.0dB = +4.5dB
･SW:NONE (DIGITAL) -2dB+12dB -0.5dB= +9.5dB
･SW:NONE (ANALOG) -2dB+12dB+6.0dB =+16.5dB
(1) (2) (3) (4)
(1):Basic OFFSET of VOL=0dB
(2):OFFSET of SW NON
(3):OFFSET of the AD input
(4):Correction system of Digital input
-2+12-0.5=9.5dB
-2+12+6=16.5dB
-2.6dB
SW:NONE
-32dBFS(DIG.IN)
-20dBFS(DIG.IN)
＋
＋
LINE IN
H/P OUT
＋
SPEAKER
OUT
DSP
ANALOG
ATT
R2A15218FP
GAIN
ADJ.
PCM1690
D/A
－
－
＋
PLD
PCM9211
A/D
-2.6dB
2.83Vrms=0dBFS
-10dBFS
-20dBFS
-30dBFS
-40dBFS
PCM1690Differential Out
-2dB
-2.6dB
-2.6dB
R2A15218FP MAX. OUTPUT 3.8Vrms
MUTE
PRE OUT
PRE OUT
159mVrms
(N Only)
-26.5dBFS(A/D IN)
SW:NONE
-38.5dBFS(A/D IN)
-12dB
4.22Vrms:A/D FULL SCALE
HDAM
109
