Marantz SR6009/U1B - Page 113

+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
SR6009
LEVEL DIAGRAM
SURR.BACK/FRONT HEIGHT/FRONT WIDE ch
-2+3-0.5dB
200mVrms
+30dB
SP OUT
4.48Vrms/8Ω
+29dB
-2+3+6=+7dB
MAX. SIGNAL LEVEL
DOLBY LIMIT LEVEL (ALLch-3dBFS)
-2.6dB
＋
＋
SPEAKER
OUT
DSP
R2A15218FP
GAIN
ADJ.
PCM1690
D/A
－
－
＋
PLD
-2.6dB
2.83Vrms=0dBFS
-10dBFS
-20dBFS
-30dBFS
-40dBFS
PCM1690Differential Out
-2.6dB
R2A15218FP MAX. OUTPUT 3.8Vrms
MUTE
PRE OUT
-2+6dB=4dB
-23dBFS(DIG.IN:DD EX Config1)
-29.5BFS(A/D IN)
-26.5dBFS(DIG.IN DD Config2)
INPUT : -20dBFS(DIG.IN) D.D
INPUT : 200mV(A/D IN)
Mch STEREO
PRE OUT
159mVrms
HDAM
(N Only)
113
