Marantz SR6009/U1B - Page 183

FRONT
1
FRONT PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D6003 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D6005-6007 00D9630328409 DIODE,RECTIFIER,AXIAL CVD1N4007ST 3
D6015 00D9430087209 DIODE,ZENER,1/2W,24V CVDZJ24BT 1
D6016 943202007690S DIODE,ZENER,1/2W,18V CVDZJ18BT 1
D6018 00D9630328409 DIODE,RECTIFIER,AXIAL CVD1N4007ST 1
D6022-6024 943202500730S DIODE,ZENER(5.1V/0.5W,SOD-123) CVDMM1Z5V1H 3
D6028,6029 263010046507S LED,SUPERRED
CVDBLBUF4V5K1AV
2
D6034-6036 963209003510S DIODE,RELIABLEESDPROTECTION
CVDCDS3C05HDMI1
3
D6037 943263100860M L.E.D,(GREEN/RED3PI)
CVDWEJ3290W-R2H
1
IC601,602 943232100380S I.C,DUALOPAMP(SOP-8P) CVINJM8080G 2
IC603 963231101200S I.C,REGULATOR(ADJ/TO-252) CVINJM2887DL3 1
Q6001 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q6003 943219006820S T.R CVTKTC1027YT 1
Q6005,6006 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 2
Q6011,6012 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 2
Q6013 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 1
Q6015,6016 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 2
RESISTOR GROUP
R6001 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R6002 nsp RES,CHIP(1608/5%/120Kohm) CRJ10DJ124T 1
R6003-6005 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 3
R6007 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R6008 nsp RES,CHIP(1608/5%/75Kohm) CRJ10DJ753T 1
R6009 nsp RES,CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R6010 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R6014 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R6018 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R6019 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R6021 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R6022,6023 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R6024,6025 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R6029 nsp RES,CHIP(1608/5%/300ohm) CRJ10DJ301T 1
R6030 nsp RES,CHIP(1608/5%/150ohm) CRJ10DJ151T 1
R6031 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6036 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R6039 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6040 nsp
RES,CHIP(1608/5%/150ohm) CRJ10DJ151T 1
R6047 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6048 nsp RES,CHIP(1608/5%/150ohm) CRJ10DJ151T 1
R6050 nsp RES,CHIP(1608/5%/390ohm) CRJ10DJ391T 1
R6076,6077 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R6082,6083 nsp RES,CHIP(1608/5%/10ohm) CRJ10DJ100T 2
R6086 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6090 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R6091 nsp RES,CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R6092 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6093,6094 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R6095 nsp RES,CHIP(1608/5%/18Kohm) CRJ10DJ183T 1
R6096 nsp RES,CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R6098-6100 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 3
R6103-6106 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 4
R6107,6108 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R6109,6110 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R6111 nsp RES,CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R6112,6113 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R6114,6115 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R6118 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R6121,6122 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R6124,6125 nsp RES,CHIP(1608/5%/1.2Kohm) CRJ10DJ122T 2
CAPACIITORS GROUP
C6001 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 1
C6003 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C6006-6008 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG CCUS1H101JAS 3
C6009 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C6010 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C6011-6013 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 3
C6015 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C6021,6022 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 2
C6029 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C6032 nsp CAP,ELECT(63V/220uF) CCEA1JH221E 1
C6039 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C6041 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C6042 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG CCUS1H101JAS 1
C6043 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C6047 nsp CAP,CHIP(1608,50V/82pF,C0G)_SAMSUNG CCUS1H820JAS 1
C6048 nsp CAP,ELECT(16V/100uF) CCEA1CH101T 1
C6051,6052 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 2
C6057,6058 nsp CAP,ELECT(50V/10uF)-S CCEA1HKS100T 2
C6059,6060 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG CCUS1H331JAS 2
C6061,6062 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 2
C6068 nsp CAP,ELECT(10V/220uF)-S CCEA1AKS221T 1
C6069 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C6072,6073 nsp CAP,CHIP(1608,50V/0.047uF,X7R)_SAMSUNG CCUS1H473KCS 2
C6075 nsp CAP,ELECT(50V/10uF)-S CCEA1HKS100T 1
C6076,6077 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 2
C6078 nsp CAP,CHIP(2012,10V/2.2uF,X5R)_SAMSUNG CCUC1A225KCS 1
C6080 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS
1
C6081,6082 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG CCUS1H102KCS 2
C6087,6088 nsp CAP,CHIP(1608,50V/0.047uF,X7R)_SAMSUNG CCUS1H473KCS 2
C6091 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C6098,6099 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 2
C6110 nsp CAP,ELECT(50V/1uF)-S CCEA1HKS1R0T 1
C6118 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C6119 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C6121 nsp RES,CHIP(1608/5%/10ohm) CRJ10DJ100T 1
C6220 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C6231,6232 nsp CAP,CHIP(1608,50V/0.047uF,X7R)_SAMSUNG CCUS1H473KCS 2
