INPUT
7
INPUT PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D8113-8116 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 4
D8163-8166 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 4
D8213-8216 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 4
D8263-8266 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 4
D8513 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 1
D8831-8833 943203003150S DIODE,RECTIFIER,RADIAL CVD1N4007SRT 3
D8834 943202500720S DIODE,ZENER(3.6V/0.5W,SOD-123) CVDMM1Z3V6H 1
IC466 943232100380S I.C,DUALOPAMP(SOP-8P) CVINJM8080G 1
IC471 943235003810S I.C,INPUTWITH8CHVOLUME(100PQFP) CVIR2A15218FP 1
IC481-483 943232100380S I.C,DUALOPAMP(SOP-8P) CVINJM8080G 3
IC484 00D2623727904 I.C,2CHVOLUME CVINJW1194V 1
Q8105,8106 00D9430058908 T.R,CHIP,SOT-23 HVTKTA1504SYRTK 2
Q8107,8108 00D2730464901 T.R,CHIP,SOT-23
HVTKTC3875SYRTK
2
Q8113,8114 00D2730464901 T.R,CHIP,SOT-23
HVTKTC3875SYRTK
2
Q8115,8116 00D9430058908 T.R,CHIP,SOT-23 HVTKTA1504SYRTK 2
Q8121,8122 00D9430058908 T.R,CHIP,SOT-23 HVTKTA1504SYRTK 2
Q8123,8124 00D2730464901 T.R,CHIP,SOT-23
HVTKTC3875SYRTK
2
Q8127,8128 00D9430058908 T.R,CHIP,SOT-23 HVTKTA1504SYRTK 2
Q8129,8130 00D2730464901 T.R,CHIP,SOT-23
HVTKTC3875SYRTK
2
Q8135,8136 00D2730464901 T.R,CHIP,SOT-23
HVTKTC3875SYRTK
2
Q8137,8138 00D9430058908 T.R,CHIP,SOT-23 HVTKTA1504SYRTK 2
Q8155,8156 00D9430058908 T.R,CHIP,SOT-23 HVTKTA1504SYRTK 2
Q8157,8158 00D2730464901 T.R,CHIP,SOT-23
HVTKTC3875SYRTK
2
Q8163,8164 00D2730464901 T.R,CHIP,SOT-23
HVTKTC3875SYRTK
2
Q8165,8166 00D9430058908 T.R,CHIP,SOT-23 HVTKTA1504SYRTK 2
Q8171,8172 00D9430058908 T.R,CHIP,SOT-23 HVTKTA1504SYRTK 2
Q8173,8174 00D2730464901 T.R,CHIP,SOT-23
HVTKTC3875SYRTK
2
Q8177,8178 00D9430058908 T.R,CHIP,SOT-23 HVTKTA1504SYRTK 2
Q8179,8180 00D2730464901 T.R,CHIP,SOT-23
HVTKTC3875SYRTK
2
Q8185,8186 00D2730464901 T.R,CHIP,SOT-23
HVTKTC3875SYRTK
2
Q8187,8188 00D9430058908 T.R,CHIP,SOT-23 HVTKTA1504SYRTK 2
Q8205,8206 00D9430058908 T.R,CHIP,SOT-23 HVTKTA1504SYRTK 2
Q8207,8208 00D2730464901 T.R,CHIP,SOT-23
HVTKTC3875SYRTK
2
Q8213,8214 00D2730464901 T.R,CHIP,SOT-23
HVTKTC3875SYRTK
2
Q8215,8216 00D9430058908 T.R,CHIP,SOT-23 HVTKTA1504SYRTK 2
Q8221,8222 00D9430058908 T.R,CHIP,SOT-23 HVTKTA1504SYRTK 2
Q8223,8224 00D2730464901 T.R,CHIP,SOT-23
HVTKTC3875SYRTK
2
Q8227,8228 00D9430058908 T.R,CHIP,SOT-23 HVTKTA1504SYRTK 2
Q8229,8230 00D2730464901 T.R,CHIP,SOT-23
HVTKTC3875SYRTK
2
Q8235,8236 00D2730464901 T.R,CHIP,SOT-23
HVTKTC3875SYRTK
2
Q8237,8238 00D9430058908 T.R,CHIP,SOT-23 HVTKTA1504SYRTK 2
Q8255,8256 00D9430058908 T.R,CHIP,SOT-23 HVTKTA1504SYRTK 2
Q8257,8258 00D2730464901 T.R,CHIP,SOT-23
HVTKTC3875SYRTK
2
Q8263,8264 00D2730464901 T.R,CHIP,SOT-23
HVTKTC3875SYRTK
2
Q8265,8266 00D9430058908 T.R,CHIP,SOT-23 HVTKTA1504SYRTK 2
Q8271,8272 00D9430058908 T.R,CHIP,SOT-23 HVTKTA1504SYRTK 2
Q8273,8274 00D2730464901 T.R,CHIP,SOT-23
HVTKTC3875SYRTK
2
Q8277,8278 00D9430058908 T.R,CHIP,SOT-23 HVTKTA1504SYRTK 2
Q8279,8280 00D2730464901 T.R,CHIP,SOT-23
HVTKTC3875SYRTK
2
Q8285,8286 00D2730464901 T.R,CHIP,SOT-23
HVTKTC3875SYRTK
2
Q8287,8288 00D9430058908 T.R,CHIP,SOT-23 HVTKTA1504SYRTK 2
Q8511 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
Q8513 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q8514 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q8515-8518 943214500030S T.R,MUTE CVTINC2001AC1 4
Q8520 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q8535-8538 943214500030S T.R,MUTE CVTINC2001AC1 4
Q8563 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q8564 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q8565-8568 943214500030S T.R,MUTE CVTINC2001AC1 4
Q8570 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q8583 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q8584 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q8585-8588 943214500030S T.R,MUTE CVTINC2001AC1 4
Q8590 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q8615 943214500030S T.R,MUTE CVTINC2001AC1 1
Q8617 943214500030S T.R,MUTE CVTINC2001AC1 1
Q8743 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q8744 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q8745-8748 943214500030S T.R,MUTE CVTINC2001AC1 4
Q8750 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
RESISTOR GROUP
R4601,4602 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R4603,4604 nsp RES,CHIP(1608/5%/820Kohm) CRJ10DJ824T 2
R4605,4606 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R4607,4608 nsp RES,CHIP(1608/5%/820Kohm) CRJ10DJ824T 2
R4609,4610 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R4611,4612 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R4613,4614 nsp RES,CHIP(1608/5%/820Kohm) CRJ10DJ824T 2
R4615,4616 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R4617,4618 nsp RES,CHIP(1608/5%/820Kohm) CRJ10DJ824T 2
R4619,4620 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R4625,4626 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R4627,4628 nsp RES,CHIP(1608/5%/820Kohm) CRJ10DJ824T 2
R4629,4630 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R4631,4632 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R4633,4634 nsp RES,CHIP(1608/5%/820Kohm) CRJ10DJ824T 2
R4635,4636 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R4637,4638 nsp RES,CHIP(1608/5%/820Kohm) CRJ10DJ824T 2
R4639,4640 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R4641,4642 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R4643,4644 nsp RES,CHIP(1608/5%/820Kohm) CRJ10DJ824T 2
R4645,4646 nsp RES,CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R4647,4648 nsp RES,CHIP(1608/5%/820Kohm) CRJ10DJ824T 2
R4649,4650 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R4661 nsp RES,CHIP(1608/5%/0ohm) U CRJ10DJ0R0T 1
R4661 nsp RES,CHIP(1608/5%/4.7Kohm) N CRJ10DJ472T 1
