Marantz SR6009/U1B - Page 210

DIGITAL
28
REF No. Part No.
Part Name Remarks Q'ty New Ver
C5091 nsp
CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG
CY920 Model CCUI1C104KCS 1 2
C5092,5093 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CY920 Model CCUS1A105KCS 2 2
C5094 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CY920 Model CCUI1C104KCS 1 2
C5101 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CCUI1C104KCS 1
C5111 nsp CAP,CHIP(1005,25V/0.022uF,X7R)_SAMSUNG CCUI1E223KCS 1
OTHER PARTS GROUP
BK102,103 nsp BRACKET,PCB CMD1A569-V1 2
BK501,502 nsp BRACKET,NETWORKA CMD1A900 2
BN111
EXPLODED_C18
nsp WIREASS'Y(4P,2.0MM,120MM,UL1007#24) CWB1C004120LC 1
BN21A nsp PINSOCKET(19P,1.25mm,ANGLE,B-TO-B) CJP19HJ282Z 1
BN23A,24 nsp PINSOCKET(27P,1.25mm,ANGLE,B-TO-B) CJP27HJ282Z 2
BN25A nsp PINSOCKET(23P,1.25mm,ANGLE,B-TO-B) CJP23HJ282Z 1
BN26A nsp PINSOCKET(09P,1.25mm,ANGLE,B-TO-B) CJP09HJ282Z 1
BN27A nsp PINSOCKET(15P,1.25mm,ANGLE,B-TO-B) CJP15HJ282Z 1
CN431 nsp WAFER,FFC,SMD(23P-1mm,STRAIGHT) CJP23GA193ZY 1
CN501,502 nsp WAFER,64pin(2x32x1.27mm)SMDTYPE CJP64GA312ZP 2
CN503 nsp LOCK-WAFER/ANGLE/2MMPITCH/5PIN CY920 Model CJP05GI288ZY 1 2
CN69B nsp WAFER,FFC,SMD(40P-1mm,STRAIGHT) CJP40GA193ZY 1
CN704 nsp WAFER,2mm,SMD,Vertical,07p CJP07GA208ZY 1
CN903 nsp LOCK-WAFER/STRAIGHT/2.5MMPITCH/5PIN CJP05GI289ZY 1
JK201 90M-YT003480R JACK,2P(B/B),GOLD CJJ4N023Z 1
JK202,203 943262100150S MODULE,OPTICAL(RX16MHz) CJSJSR1124 2
JK381-384 943643102920S JACK,HDMI(TYPE-A,SMT-19P,WITHFLANGE) CJJ9H021Z 4
JK391-394 943643102920S JACK,HDMI(TYPE-A,SMT-19P,WITHFLANGE) CJJ9H021Z 4
JK431 943643102920S JACK,HDMI(TYPE-A,SMT-19P,WITHFLANGE) CJJ9H021Z 1
JK501 943643102430S JACK,RJ-45W/TRANSFORMER CJJ9L029Z 1
JW501 nsp WIREASS'Y(1P,80MM,BLK,#22) CWE5202080A 1
JW503,504 nsp WIREASS'Y(1P,80MM,BLK,#22) CWE5202080A 2
JW507 nsp WIREASS'Y(1P,80MM,BLK,#22) CWE5202080A 1
L1001 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
L1003,1004 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 2
L1005,1006 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
L1007 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1008 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
L1009 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600)
CLZ9R005V 1
L1010-1012 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 3
L1013,1014 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 2
L1015-1033 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 19
L1111 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1113,1114 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 2
L1121 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1124 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1131 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1134 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1141 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1144 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1151 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1154 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1161 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1164 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1171 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1174 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1181 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1184 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1191 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1194 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1201 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1204 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1211-1213 nsp FERRITECHIPBEAD(2012/220R)
CLZBLM21PG221SN
3
L1214 nsp FERRITECHIPBEAD(2012/120R)
CLZBLM21AG121SN
1
L3501-3513 nsp FERRITECHIPBEAD(2012/220R)
CLZBLM21PG221SN
13
L3801-3808 nsp FERRITECHIPBEAD(2012/220R)
CLZBLM21PG221SN
8
L3901-3908 nsp FERRITECHIPBEAD(2012/220R)
CLZBLM21PG221SN
8
L3909 943113100000S COMMONMODEFILTER(1210,90ohm) CLZ9Z188Z 1
L4001-4008 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 8
L4010 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L4012-4016 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 5
L4301-4308 nsp FERRITECHIPBEAD(2012/220R)
CLZBLM21PG221SN
8
L4309 943113100000S COMMONMODEFILTER(1210,90ohm) CLZ9Z188Z 1
L5091 nsp RES,CHIP(2012/5%/0ohm) CY920 Model CRJ18AJ0R0T 1 2
L5111,5112 nsp COMMONMODEFILTER(2012,90ohm) CLZ9Z174Z 2
X1501 943141101260S X-TAL,SMD(12MHz/8pF,FA-238V,3.2X2.5) COX12000I080SP 1
X1701 943141101260S X-TAL,SMD(12MHz/8pF,FA-238V,3.2X2.5) COX12000I080SP 1
X2001 943141101310S X-TAL,SMD(24.576MHz/10pF,FA-238,3.2X2.5) COX24576I100SP 1 *
X2501 943141101280S X-TAL,SMD(25MHz/12pF,FA-238,3.2X2.5) COX25000I120SP 1
X3501 943141101300S X-TAL,SMD(27MHz/12pF,FA-238,3.2X2.5) COX27000I120SP 1
X3801 943141101290S X-TAL,SMD(27MHz/7pF,FA-238,3.2X2.5) COX27000I070SP 1
X3901 943141101290S X-TAL,SMD(27MHz/7pF,FA-238,3.2X2.5) COX27000I070SP 1
X4001 943141101300S X-TAL,SMD(27MHz/12pF,FA-238,3.2X2.5) COX27000I120SP 1
X4301 943141101290S X-TAL,SMD(27MHz/7pF,FA-238,3.2X2.5) COX27000I070SP 1
