EXPLODED
30
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
C17 9U6391018300M DIGITAL PCB ASSY (U) U CX870 Model COP12720Q 1 *
C17 9U6391018000M DIGITAL PCB ASSY (N) N CX870 Model COP12720R 1 *
C17 9U6391016500M DIGITAL PCB ASSY (U) U CY920 Model COP12638Q 1 * 2
C17 9U6391016600M DIGITAL PCB ASSY (N) N CY920 Model COP12638R 1 * 2
C20 943639101590D CX870 MIDDLE / BT BASE ASSY(U/N) COP12666M-1 1
┗C7
- BLUETOOTH PCB COP12666M-2 1
C19 943189101240M CX870 MODULE ASSY (U) U CX870 Model CVIANAM2070AV 1 *
C19 943189101210M CX870 MODULE ASSY (N) N CX870 Model CVIANAM2071AV 1 *
C19 943189100890M CY920 MODULE ASSY CY920 Model CVIANAM2026AV 1 * 2
C42-1 943116100570S WIFI ANT WIRE ASSY 450MM - 1 * 3
C42-2 943116100580S WIFI ANT WIRE ASSY 300MM - 1 * 3
C5 943639101810M F_HDMIPCBMANUALASS'Y COP12640Q 1 *
C16 nsp VIDEO PCB COP12534U-1 1 *
C1 nsp FRONT PCB COP12624Q-1 1 *
┣C13
- GUIDE TOP PCB COP12624Q-3 1 *
┗C4
-
HDMI FFC TOP PCB COP12624Q-4
1
*
C11 nsp AMP PCB COP12625Q 1 *
C33 nsp SPK PCB U COP12627Q-1 1 *
C33 nsp SPK PCB N COP12627R-1 1 *
┗C31
-
FUSE PCB U COP12627Q-3 1 *
┗C31
- FUSE PCB N COP12627R-3 1 *
C30 nsp FRT CNT PCB COP12630Q-1 1 *
┣C32
- SIDE CNT PCB
COP12630Q-2
1 *
┣C10
- GUIDE R PCB COP12630Q-3 1 *
┗C9
-
GUIDE L PCB
COP12630Q-4 1 *
C14 nsp INPUT PCB COP12634Q-1 1 *
C22 nsp SMPS PCB U COP12641M 1
C22 nsp SMPS PCB N COP12641N 1 *
C3 943606502600S CARDCABLE(1mm/40P/310mm/B/SHIELD)
1 *
C6 943606502540S CARDCABLE(1mm/23P/280mm/B/SHIELD)
1
! C21 943101102520D TRANS,POWER(EI96X65)
U CLT5V068ZU 1
! C21 943101102530D TRANS,POWER(EI96X65)
N CLT5V068ZE 1
C43 - 2PWIREASS'Y(100MM) CWZPM5003TW91A 1
┣TW91
nsp
2PWIREASS'Y(100MM)
CWZPM5003TW91 1
!
┗RT01
00MYJ04002640 RECEPTACLE,AC(15A/250V,R-301,B21) CJJ8A006ZW 1
C44 nsp TERMINAL,GROUND CMA1A006 1
M1 421410006004M BADGE,MARANTZ CGB1A206 1
M2 943402104840M PANEL AL FRONT (U) U1B CKM1A249QC23 1 *
M2 943402104820M PANEL AL FRONT (N1B) N1B CKM1A249PC23 1 *
M2 943402104810M PANEL AL FRONT (N1SG) N1SG CKM1A249OC62 1 *
M3 412410005014M VOLUMEKNOBASS'Y BK CGK1A133YA 2
M3 943412002020M VOLUMEKNOBASS'Y SG CGK1A133XA 2
M4 943417100520M DOOR AL(BK) BK CKM1A278C23 1 *
M4 943417100530M DOOR AL(SG) SG CKM1A278C62 1 *
M5 00M10BW112010 BASE,SHAFT CDF1A018 2
M6 00M10BW104010 BRACKET,BASE CMD1A542 1
M7 00M10BW305010 MAGNET,BASE CJC1A008 1
M8 nsp EARTH,USB CMC1A435 1
M9 nsp EARTH,AUX CMC1A434 1
M10 nsp EARTH,FRONT CMC1A437 1
M11 nsp EARTH,EMC CMC1A456 1
M12 943403101120D TOP COVER(BK) BK CKC3A155K117 1
M12 943403101130D TOP COVER(SG) SG CKC3A155D11 1
M13 nsp CHASSIS,BOTTOM CUA1A358 1 *
M14 nsp HEATSINK CMY1A372-V1 1
M15 nsp BRACKET,AMPPCB CMD1A796 5
M16 nsp SMPSBRACKET CMD1A790 1
M20 nsp PCBBRACKET(HDMI) CMD1A791 1
M21 nsp PANEL,REAR U
CKF3A483Z 1 *
M21 nsp PANEL,REAR N CKF3A483Y 1 *
M22 nsp WASHER,GROUND CNW1A035 4
M23 nsp NUT - 2
M24 nsp WASHER - 2
P1 481510019100M LENS,IR BK CGU1A460 1
P1 481510019131M LENS,IR SG CGU1A460Y 1
P2 943424100400M ORNAMENT,RING BK CGR1A525 1
P2 943424100420M ORNAMENT,RING SG CGR1A525C73 1
P3 416510046009M WINDOW CGU1A455 1
P4 416510047101M SHEET,VFD CGX1A449Y 1
P5 424510002017M ORNAMENT,VOLUME BK CGR1A449B37 2
P5 943424002030M ORNAMENT,VOLUME SG CGR1A449RMD10 2
P6 943422101040M ORNAMENT,INNERDOOR BK CGR1A578Z 1 *
P6 943422101030M ORNAMENT,INNERDOOR SG CGR1A578RMYD10 1 *
P7 454510002018M HOLDER,DOORAV8003 BK CKG1A053B37 1
P7 417510015039M HOLDER,DOOR SG CKG1A053RMD10 1
P8 943411103370M ORNAMENT,BUTTON BK CGX1A506Z 1 *
P8 943411103360M ORNAMENT,BUTTON SG CGX1A506Y 1 *
P9 943443101050M PANEL,FRONT BK CGW1A557RNZB37 1 *
P9 943443101060M PANEL,FRONT SG CGW1A557ROYD10 1 *
P10 411510015017M KNOB,TACTPOWERAV8003/U BK CBT1A1072 1
P10 411510021036M KNOB,POWER
SG CBT1A1072RMD10 1
P11 00M10BW355010 INDICATOR,POWER CGL1A231 1
P12 943474001390S GEAR,DEMPERAV8003 CDG1A027Z 1
P13 nsp COVER,DAMPER BK CMH1A368 1 *
P13 nsp COVER,DAMPER SG CMH1A368RO 1 *
P14 943411103340M BUTTON,9KEY BK CBT1A1198B37 1 *
P14 943411103350M BUTTON,9KEY SG CBT1A1198RMD10 1 *
P15 00M243W057210 FOOT,FRONT CKL2A042H46 4
P16 nsp EOLitemCUSHION,FOOT CHG1A360 4
P17 nsp RUBBER CHG1A113 5
P18 nsp HOLDER,PCB CHE170 3
P19 nsp SUPPORT,RUBBER CHG1A535 1
P20 nsp SUPPORT,PCB CRE1A102 1
P21 nsp SUPPORT,PCB31 CRE1A073 1
P22 nsp ORNAMENT,REARPANEL CGX1A490Z 1
S1 nsp SCREW BK CTB3+8JFZR 9
S1 nsp SCREW SG CTB3+8JFN 9
To Next Page
