Marantz SR6009/U1B - Page 214

PACING
32
PACING
※Parts indicated by "nsp"on this table cannot be supplied.
※
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
1 nsp SET,AVRECEIVER U1B SR6009/U1BSET 1 *
1 nsp SET,AVRECEIVER N1B SR6009/N1BSET 1 *
1 nsp SET,AVRECEIVER N1SG SR6009/N1SGSET 1 *
2 nsp POLYSHEET CPB1A213 1
4 943533102660M PAD SNOW (BOTTOM) CPS1A942-V1 1 *
5 943533102690M PAD SNOW (TOP) CPS1A995 1 *
6 943531104540M BOX OUT CARTON CPG1A1029Z 1 *
8 - INSTRUCTIONMANUALASS'Y U CQXSR6009/U 1 *
8 - INSTRUCTIONMANUALASS'Y N CQXSR6009/N 1 *
8-1 35201035300AM INSTRUCTION MANUAL (U) U CFT1A142ZA 1 *
8-1 35201035301AM INSTRUCTION MANUAL (N) N CFT1A143ZA 1 *
8-2 54111119700AM QUICK MANUAL(U) U CQX1A1829Z 1 *
8-2 54111119701AM QUICK MANUAL(N) N CQX1A1830Z 1 *
8-3 nsp BAG,ZIPPERPOLY(A5) CPB1A227Z 1
9 - ACCESSORYASS'Y U CSASR6009/U 1 *
9 - ACCESSORYASS'Y N CSASR6009/N 1 *
9-1 nsp BAG,POLY CPB1A216Z 1
9-2 943543104030M LABEL,SPEAKERCABLE CQB1A1262Z 1 *
9-3 nsp CARD,WARRANTY U CQE1A131V 1
9-3 nsp
WARRANTYCANADA U CQE1A132V 1
9-4 nsp SAFETYINSTRUCTION U CQE1A724Z 1 *
9-5 nsp NOTESONRADIO CQE1A725Z 1 *
9-6 nsp LABEL , AM ANTENNA CQB1A1240Z
9-7 nsp LABEL , FM ANTENNA CQB1A1241Z
9-8 963116100070S ANT,AMLOOP(9.5uH/5T) CSA1A039Y 1
9-9 943116100170D FM1POLEANT(ULTYPE) CSA1A044Z 1
10 - WIFI-FLYSHEETASS'Y CQE1A728ZA 1 *
10-1 nsp POLY,BAG CPB1A240Z 1 *
10-2 nsp SHEET,WIFIANTENNAFLY CQE1A728Z 1 *
10-3 11601005400AS WI-FI ANTENNA(RFDPA870900SBAB801) - 2
11 963549101000D MICSTANDASS'Y CPG1A1021ZA 1
! 12 943611500750D CORD,POWER(PLUG+SOCKET)UL,(WHITEBANDING) U CJA2A119YL 1
! 12 943611500760D CORD,POWER(PLUG+SOCKET)EUR,(WHITEBANDING) N CJA2B120Y 1
13 nsp BAG,POLY CPB1A008Z 1
14 30701020500AM REMOCONASS'Y(RC025SR) CARTSR6009 1 *
15 nsp BATTERY,AAA2PCSINPACK CABR03PPB 2
16 32401000800AD MIC,AUDYSSEY CJXACM1HB 1
17 nsp LABEL,MIC CQB1A1242Z 1
18 nsp LABEL,CONTROL CQB2A993Z 1
┗18-1
-
LABEL , CONTROL (SERIAL No.)
- 1
20
EXPLODED_P24
nsp LABEL,POP U CQB1A1284Z 1 *
20
EXPLODED_P24
nsp LABEL,POP N CQB1A1285Z 1 *
22 LABEL,SPOTIFY U/N CQB1A1299Z 1
23
EXPLODED_P23
nsp LABEL,LICENSE U CQB1A1312Z 1 *
23
EXPLODED_P23
nsp LABEL,LICENSE N CQB1A1296Z 1
24 nsp LABEL,SIRIUSSPOTIFY U CQB1A1317Z 1 *
24 nsp LABEL,SPOTIFY N CQB1A1318Z 1 *
25 nsp LABEL,WHITEM1SG SG CQB1A908Z 2
