Example connections when using front wide speakers

This 7.1-channel surround system is the same as a basic 5.1-channel system but with front wide speakers.

FWL FWR

FWLFWR

FR FL C SR SL

Set “Floor” - “Layout” to “5ch & SB & FW” or “5ch & FW” in the menu when connecting in this configuration. (v p. 217)
