NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR8200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
P114- POWER AMP FL FR SBL
CIRCUIT BOARD
P114- CAPACITORS
C101 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
C103 4822 124 90355 ELECT.100µF ±20% 50V RA-2 OA10705020
C105 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
C106 4822 124 23068 ELECT.220µF ±20% 63V RA-2 OA22706320
C107 4822 124 23068 ELECT.220µF ±20% 63V RA-2 OA22706320
C111 4822 122 32185 CER.10pF D CH 50V BLK DD11100300
C112 CER.47pF ±5% SL 500V DD15470560
C113 CER.47pF ±5% SL 500V DD15470560
C148 4822 124 41535 ELECT.100µF ±20% 25V RA-2 OA10702520
C149 4822 124 41535 ELECT.100µF ±20% 25V RA-2 OA10702520
C201 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
C203 4822 124 90355 ELECT.100µF ±20% 50V RA-2 OA10705020
C205 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
C206 4822 124 23068 ELECT.220µF ±20% 63V RA-2 OA22706320
C207 4822 124 23068 ELECT.220µF ±20% 63V RA-2 OA22706320
C211 4822 122 32185 CER.10pF D CH 50V BLK DD11100300
C212 CER.47pF ±5% SL 500V DD15470560
C213 CER.47pF ±5% SL 500V DD15470560
C301 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
C303 4822 124 90355 ELECT.100µF ±20% 50V RA-2 OA10705020
C305 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
C306 4822 124 23068 ELECT.220µF ±20% 63V RA-2 OA22706320
C307 4822 124 23068 ELECT.220µF ±20% 63V RA-2 OA22706320
C311 4822 122 32185 CER.10pF D CH 50V BLK DD11100300
C312 CER.47pF ±5% SL 500V DD15470560
C313 CER.47pF ±5% SL 500V DD15470560
C348 4822 124 41535 ELECT.100µF ±20% 25V RA-2 OA10702520
C349 4822 124 41535 ELECT.100µF ±20% 25V RA-2 OA10702520
CN14 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CN18 4822 124 41543 ELECT.1µF ±20% 50V RA-2 OA10505020
CN66 4822 124 41543 ELECT.1µF ±20% 50V RA-2 OA10505020
P114-CAPACITORS(COMMON)
PLASTIC FILM CAPACI TOR
±5% 50V : C104 C108 C154
C204 C208 C254 C308 C304
C354
HIGH DIELECTRIC CONSTANT
CER.CAPACITOR ±10% 50V :
C102 C152 C202 C252 C302
C352
P114- RESISTORS
R106
4822 052 10331 330 Ω ±5% 1/4W GG05331140
R109
R113 4822 052 10471 470
Ω ±5% 1/6W GG05471160
R114 4822 052 10471 470
Ω ±5% 1/6W GG05471160
R117 4822 052 10151 150
Ω ±5% 1/6W GG05151160
R118 4822 052 10151 150
Ω ±5% 1/6W GG05151160
R123 4822 100 11452 TRIM.VAR.470 VERTICAL RA04710760
R124 4822 052 10101 100
Ω ±5% 1/6W GG05101160
R125 4822 052 10101 100
Ω ±5% 1/6W GG05101160
R126 4822 050 21022 1k
Ω ±5% 1/4W GG05102140
R127 4822 052 10479 47
Ω ±5% 1/4W GG05470140
R128 4822 052 10479 47
Ω ±5% 1/4W GG05470140
R129 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R130 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R131 4822 116 83929 220
Ω ±5% 1/4W GG05221140
R132 4822 111 91422 COMPO.0.1 Ω ±10%
5WX2RGC-55 TYPE
BW10000050
R142 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R143 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R149 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R206
4822 052 10331 330 Ω ±5% 1/4W GG05331140
R209
R213 4822 052 10471 470
Ω ±5% 1/6W GG05471160
R214 4822 052 10471 470
Ω ±5% 1/6W GG05471160
R217 4822 052 10151 150
Ω ±5% 1/6W GG05151160
R218 4822 052 10151 150
Ω ±5% 1/6W GG05151160
R223 4822 100 11452 TRIM.VAR.470 VERTICAL RA04710760
R224 4822 052 10101 100
Ω ±5% 1/6W GG05101160
R225 4822 052 10101 100
Ω ±5% 1/6W GG05101160
R226 4822 050 21022 1k
Ω ±5% 1/4W GG05102140
R227 4822 052 10479 47
Ω ±5% 1/4W GG05470140
R228 4822 052 10479 47
Ω ±5% 1/4W GG05470140
R229 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R230 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R231 4822 116 83929 220
Ω ±5% 1/4W GG05221140
R232 4822 111 91422 COMPO.0.1 Ω ±10%
5WX2RGC-55 TYPE
BW10000050
R242 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R243 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R306
4822 052 10331 330 Ω ±5% 1/4W GG05331140
R309
R313 4822 052 10471 470
Ω ±5% 1/6W GG05471160
R314 4822 052 10471 470
Ω ±5% 1/6W GG05471160
R317 4822 052 10151 150
Ω ±5% 1/6W GG05151160
R318 4822 052 10151 150
Ω ±5% 1/6W GG05151160
R323 4822 100 11452 TRIM.VAR.470 VERTICAL RA04710760
R324 4822 052 10101 100
Ω ±5% 1/6W GG05101160
R325 4822 052 10101 100
Ω ±5% 1/6W GG05101160
R326 4822 050 21022 1k
Ω ±5% 1/4W GG05102140
R327 4822 052 10479 47
Ω ±5% 1/4W GG05470140
R328 4822 052 10479 47
Ω ±5% 1/4W GG05470140
R329 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R330 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R331 4822 116 83929 220
Ω ±5% 1/4W GG05221140
R332 4822 111 91422 COMPO.0.1 Ω ±10%
5WX2RGC-55 TYPE
BW10000050
R342 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R343 4822 052 10109 10
Ω ±5% 1/4W GG05100140
P114- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : R101 R102 R104
R105 R110-R112 R115 R116
R119 R120-R122 R133-R137
R139 R201 R202 R204 R205
R210-R212 R215 R216
R219-R222 R233-R237 R239
R301 R302 R304 R305
R310-R312 R315 R316
R319-R322 R333-R337 R339
R542-R544 RN40 RN41
P114- SEMICONDUCTORS
D101
4822 130 32362 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
D104
D105 4822 130 80273 ZENER,8.2V EQUIVALENT HD30821000
