132
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR8200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
D106 4822 130 80273 ZENER,8.2V EQUIVALENT HD30821000
D107 4822 130 80837 DIODE,HSS81TD 150V 150MA
AXIAL TAPG.
HD20027010
D108 4822 130 80837 DIODE,HSS81TD 150V 150MA
AXIAL TAPG.
HD20027010
D109 4822 130 31554 ZENER,4.3V EQUIVALENT HD30431000
D201
4822 130 32362 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
D204
D205 4822 130 80273 ZENER,8.2V EQUIVALENT HD30821000
D206 4822 130 80273 ZENER,8.2V EQUIVALENT HD30821000
D207 4822 130 80837 DIODE,HSS81TD 150V 150MA
AXIAL TAPG.
HD20027010
D208 4822 130 80837 DIODE,HSS81TD 150V 150MA
AXIAL TAPG.
HD20027010
D209 4822 130 31554 ZENER,4.3V EQUIVALENT HD30431000
D301
4822 130 32362 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
D304
D305 4822 130 80273 ZENER,8.2V EQUIVALENT HD30821000
D306 4822 130 80273 ZENER,8.2V EQUIVALENT HD30821000
D307 4822 130 80837 DIODE,HSS81TD 150V 150MA
AXIAL TAPG.
HD20027010
D308 4822 130 80837 DIODE,HSS81TD 150V 150MA
AXIAL TAPG.
HD20027010
D309 4822 130 31554 ZENER,4.3V EQUIVALENT HD30431000
Q101 4822 209 73064 IC,NJM-2068-DD HC10053090
Q103 4822 130 60107 TRS.2SA1048 Y OR GR HT110482B0
Q104 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
Q105 4822 130 43233 TRS.2SC2240 GR OR BL HT322402A0
Q106 4822 130 42949 TRS.2SA970 (GR) OR (BL) HT109702A0
Q107 4822 130 42949 TRS.2SA970 (GR) OR (BL) HT109702A0
Q108 4822 130 43233 TRS.2SC2240 GR OR BL HT322402A0
Q109 4822 130 42999 TRS.2SA1145 O OR Y TAPING HT111452A0
Q110 4822 130 43283 TRS.2SC2705 O OR Y TAPING HT327052A0
Q111 4822 130 60117 TRS.C3419 Y 40V 0.8A
PC=1.2W (5W)
HT334191Y0
Q112 4822 130 63312 TRS.2SC4883 O OR Y HT348832A0
Q113 4822 130 63308 TRS.2SA1859 O OR Y HT118592A0
Q114 4822 130 60354 TRS.C3421 OY 120V 1A
PC1.5W(10W)
HT334212A0
Q115 4822 130 60353 TRS.A1358 OY 120V 1A
PC1.5W(10W)
HT113582A0
Q116 4822 130 10962 TRS.C3856 OPY 15A 130W
LF119
HT338563A0
Q117 4822 130 10963 TRS.A1492 OPY 15A 130W
LF119
HT114923A0
Q118 4822 130 43233 TRS.2SC2240 GR OR BL HT322402A0
Q203 4822 130 60107 TRS.2SA1048 Y OR GR HT110482B0
Q204 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
Q205 4822 130 43233 TRS.2SC2240 GR OR BL HT322402A0
Q206 4822 130 42949 TRS.2SA970 (GR) OR (BL) HT109702A0
Q207 4822 130 42949 TRS.2SA970 (GR) OR (BL) HT109702A0
Q208 4822 130 43233 TRS.2SC2240 GR OR BL HT322402A0
Q209 4822 130 42999 TRS.2SA1145 O OR Y TAPING HT111452A0
Q210 4822 130 43283 TRS.2SC2705 O OR Y TAPING HT327052A0
Q211 4822 130 60117 TRS.C3419 Y 40V 0.8A
PC=1.2W (5W)
HT334191Y0
Q212 4822 130 63312 TRS.2SC4883 O OR Y HT348832A0
Q213 4822 130 63308 TRS.2SA1859 O OR Y HT118592A0
Q214 4822 130 60354 TRS.C3421 OY 120V 1A
PC1.5W(10W)
HT334212A0
Q215 4822 130 60353 TRS.A1358 OY 120V 1A
PC1.5W(10W)
HT113582A0
Q216 4822 130 10962 TRS.C3856 OPY 15A 130W
LF119
HT338563A0
Q217 4822 130 10963 TRS.A1492 OPY 15A 130W
LF119
HT114923A0
Q218 4822 130 43233 TRS.2SC2240 GR OR BL HT322402A0
Q301 4822 209 73064 IC,NJM-2068-DD HC10053090
Q303 4822 130 60107 TRS.2SA1048 Y OR GR HT110482B0
Q304 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
Q305 4822 130 43233 TRS.2SC2240 GR OR BL HT322402A0
Q306 4822 130 42949 TRS.2SA970 (GR) OR (BL) HT109702A0
Q307 4822 130 42949 TRS.2SA970 (GR) OR (BL) HT109702A0
Q308 4822 130 43233 TRS.2SC2240 GR OR BL HT322402A0
Q309 4822 130 42999 TRS.2SA1145 O OR Y TAPING HT111452A0
Q310 4822 130 43283 TRS.2SC2705 O OR Y TAPING HT327052A0
Q311 4822 130 60117 TRS.C3419 Y 40V 0.8A
PC=1.2W (5W)
HT334191Y0
Q312 4822 130 63312 TRS.2SC4883 O OR Y HT348832A0
Q313 4822 130 63308 TRS.2SA1859 O OR Y HT118592A0
Q314 4822 130 60354 TRS.C3421 OY 120V 1A
PC1.5W(10W)
HT334212A0
Q315 4822 130 60353 TRS.A1358 OY 120V 1A
PC1.5W(10W)
HT113582A0
Q316 4822 130 10962 TRS.C3856 OPY 15A 130W
LF119
HT338563A0
Q317 4822 130 10963 TRS.A1492 OPY 15A 130W
LF119
HT114923A0
Q318 4822 130 43233 TRS.2SC2240 GR OR BL HT322402A0
QN08 4822 130 42949 TRS.2SA970 (GR) OR (BL) HT109702A0
P114- MISCELLANEOUS
K101 4822 130 60795 TRS.KIT,A1358,C3421
O OR A1358,C3421 Y
HK135819C0
K102 4822 130 10964 TRS.KIT,2SA1492/2SC3856
OPY LF119
HK149219A0
K103 4822 130 10965 TRS.KIT,2SA1859/C4883
O/O OR Y/Y PAIR
HK185919C0
K201 4822 130 60795 TRS.KIT,A1358,C3421
O OR A1358,C3421 Y
HK135819C0
K202 4822 130 10964 TRS.KIT,2SA1492/2SC3856
OPY LF119
HK149219A0
K203 4822 130 10965 TRS.KIT,2SA1859/C4883
O/O OR Y/Y PAIR
HK185919C0
K301 4822 130 60795 TRS.KIT,A1358,C3421
O OR A1358,C3421 Y
HK135819C0
K302 4822 130 10964 TRS.KIT,2SA1492/2SC3856
OPY LF119
HK149219A0
K303 4822 130 10965 TRS.KIT,2SA1859/C4883
O/O OR Y/Y PAIR
HK185919C0
P124- SPKOUTS
FRONT SURRBACK HEAD
CIRCUIT BOARD
P124- CAPACITORS
CN10 4822 126 10364 CER.100pF UP050B101K-A DA16101110
CN11 4822 126 10364 CER.100pF UP050B101K-A DA16101110
CN12 4822 126 10364 CER.100pF UP050B101K-A DA16101110
CN93 /N/S 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CN95 /N/S 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CN96 /N/S 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
P124-CAPACITORS(COMMON)
PLASTIC FILM CAPACI TOR
±5% 50V : C109 C110 C209
C210 C309 C310
