NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR8200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
HIGH DIELECTRIC CONSTANT
CER.CAPACITOR ±10% 50V :
C119[/N/S] C219[/N/S]
C319[/N/S]
P124- RESISTORS
R138 4822 053 10109 10
Ω ±5% 1W GA05100010
R238 4822 053 10109 10
Ω ±5% 1W GA05100010
R338 4822 053 10109 10
Ω ±5% 1W GA05100010
RN35 4822 116 83929 220
Ω ±5% 1/4W GG05221140
RN37 4822 116 83929 220
Ω ±5% 1/4W GG05221140
RP91 4822 053 10331 330
Ω ±5% 1W GA05331010
RP92 4822 053 10331 330
Ω ±5% 1W GA05331010
RP93 4822 052 10331 330
Ω ±5% 1/4W GG05331140
P124- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RN27-RN32
P124- SEMICONDUCTORS
DN05 4822 130 82421 DIODE,1D3 1A/200V HD20002710
DN07 4822 130 82421 DIODE,1D3 1A/200V HD20002710
DP91 4822 130 82421 DIODE,1D3 1A/200V HD20002710
QN04 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
QN05 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
QN06 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
P124- MISCELLANEOUS
J149 9965 000 12663 TERMINAL,SPKROUT
FL FR SB 6P
YT01060030
LN01 4822 280 70354 RELAY,VB 24MBU-510
5A/240VAC
LY20240310
LN03 4822 280 70354 RELAY,VB 24MBU-510
5A/240VAC
LY20240310
LP91 9965 000 05895 RELAY,HP OUT RELAY LY20240490
P154- POWER AMP C SL SR,
AVSS SENS
CIRCUIT BOARD
P154- CAPACITORS
C151 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
C153 4822 124 90355 ELECT.100µF ±20% 50V RA-2 OA10705020
C155 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
C156 4822 124 23068 ELECT.220µF ±20% 63V RA-2 OA22706320
C157 4822 124 23068 ELECT.220µF ±20% 63V RA-2 OA22706320
C161 4822 122 32185 CER.10pF D CH 50V BLK DD11100300
C162 CER.47pF ±5% SL 500V DD15470560
C163 CER.47pF ±5% SL 500V DD15470560
C198 4822 124 41535 ELECT.100µF ±20% 25V RA-2 OA10702520
C199 4822 124 41535 ELECT.100µF ±20% 25V RA-2 OA10702520
C251 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
C253 4822 124 90355 ELECT.100µF ±20% 50V RA-2 OA10705020
C255 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
C256 4822 124 23068 ELECT.220µF ±20% 63V RA-2 OA22706320
C257 4822 124 23068 ELECT.220µF ±20% 63V RA-2 OA22706320
C261 4822 122 32185 CER.10pF D CH 50V BLK DD11100300
C262 CER.47pF ±5% SL 500V DD15470560
C263 CER.47pF ±5% SL 500V DD15470560
C351 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
C353 4822 124 90355 ELECT.100µF ±20% 50V RA-2 OA10705020
C355 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
C356 4822 124 23068 ELECT.220µF ±20% 63V RA-2 OA22706320
C357 4822 124 23068 ELECT.220µF ±20% 63V RA-2 OA22706320
C361 4822 122 32185 CER.10pF D CH 50V BLK DD11100300
C362 CER.47pF ±5% SL 500V DD15470560
C363 CER.47pF ±5% SL 500V DD15470560
C389 4822 124 41535 ELECT.100µF ±20% 25V RA-2 OA10702520
C399 4822 124 41535 ELECT.100µF ±20% 25V RA-2 OA10702520
C501
4822 126 10364 CER.100pF UP050B101K-A DA16101110
C507
C508 4822 124 41543 ELECT.1µF ±20% 50V RA-2 OA10505020
C509 4822 124 41535 ELECT.100µF ±20% 25V RA-2 OA10702520
C510 4822 124 41535 ELECT.100µF ±20% 25V RA-2 OA10702520
CN01 4822 124 90355 ELECT.100µF ±20% 50V RA-2 OA10705020
CN02 4822 122 30043 CER.0.01µF Z 50V DK18103310
CN03 4822 124 22273 ELECT.0.47µF ±20% 50V RA-2 OA47405020
CN04 4822 124 22273 ELECT.0.47µF ±20% 50V RA-2 OA47405020
CN05 4822 124 41543 ELECT.1µF ±20% 50V RA-2 OA10505020
CN06 4822 122 30043 CER.0.01µF Z 50V DK18103310
CN15 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CN17 4822 122 30043 CER.0.01µF Z 50V DK18103310
CN61 4822 124 41535 ELECT.100µF ±20% 25V RA-2 OA10702520
CN62 4822 122 30043 CER.0.01µF Z 50V DK18103310
CN63 4822 124 41543 ELECT.1µF ±20% 50V RA-2 OA10505020
CN64 4822 124 41543 ELECT.1µF ±20% 50V RA-2 OA10505020
CN65 4822 124 41543 ELECT.1µF ±20% 50V RA-2 OA10505020
P154-CAPACITORS(COMMON)
PLASTIC FILM CAPACI TOR
±5% 50V : C158 C258 C358
P154- RESISTORS
R156
4822 052 10331 330
Ω ±5% 1/4W GG05331140
R159
R163 4822 052 10471 470
Ω ±5% 1/6W GG05471160
R164 4822 052 10471 470
Ω ±5% 1/6W GG05471160
R167 4822 052 10151 150
Ω ±5% 1/6W GG05151160
R168 4822 052 10151 150
Ω ±5% 1/6W GG05151160
R173 4822 100 11452 TRIM.VAR.470 VERTICAL RA04710760
R174 4822 052 10101 100
Ω ±5% 1/6W GG05101160
R175 4822 052 10101 100
Ω ±5% 1/6W GG05101160
R176 4822 050 21022 1k
Ω ±5% 1/4W GG05102140
R177 4822 052 10479 47
Ω ±5% 1/4W GG05470140
R178 4822 052 10479 47
Ω ±5% 1/4W GG05470140
R179 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R180 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R181 4822 116 83929 220
Ω ±5% 1/4W GG05221140
R182 4822 111 91422 COMPO.0.1 Ω ±10%
5WX2RGC-55 TYPE
BW10000050
R192 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R193 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R199 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R256
4822 052 10331 330
Ω ±5% 1/4W GG05331140
R259
R263 4822 052 10471 470
Ω ±5% 1/6W GG05471160
R264 4822 052 10471 470
Ω ±5% 1/6W GG05471160
R267 4822 052 10151 150
Ω ±5% 1/6W GG05151160
R268 4822 052 10151 150
Ω ±5% 1/6W GG05151160
R273 4822 100 11452 TRIM.VAR.470 VERTICAL RA04710760
R274 4822 052 10101 100
Ω ±5% 1/6W GG05101160
R275 4822 052 10101 100
Ω ±5% 1/6W GG05101160
R276 4822 050 21022 1k
Ω ±5% 1/4W GG05102140
R277 4822 052 10479 47
Ω ±5% 1/4W GG05470140
R278 4822 052 10479 47
Ω ±5% 1/4W GG05470140
R279 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R280 4822 052 10109 10
Ω ±5% 1/4W GG05100140
